2) Slide the Media Elevator Car to the top of the primary chassis. See
NOTE: Elevator car is now positioned over the belt block bracket access cutout next to the PCB
and drive motor
3) On the Tensioning Ramp/Idler Pulley base on the primary chassis: Compress the springs until
the holes in the Tensioning Ramp are aligned with the holes in the base of the Tensioner, and
insert a 0.050 inch allen wrench through the holes. This sets the Idler Pulley to the zero
position. See Figure C–11.
Figure C–9. Elevator Bottom Plate
Figure C–10. Media Elevator Car
E A
LEVATOR SSEMBLY
Neo-9105
Figure C–10.
Neo-9106
E
XTENSION
C-13
