Appendix A
Hardware Specification
OPERATIONAL SPECIFICATION
Host SCSI Interface
Drive Configuration
Drive Compatibility
Number of Cartridges
Maximum Data Capacity (native)
Maximum Transfer Rate
Mount Time, into Drive
Dismount Time, from Drive
RELIABILITY
MTBF
MSBF
Design Life
MTTR
PHYSICAL CHARACTERISTICS (Tabletop Version)
Height
Width
Depth (including drive handles)
Specification
Table A–1 Hardware Specification
Neo Series 2000
LVD/SE
0, 1, 2
Quantum SDLT and DLT
8000 LTO Ultrium 200
26 removable (all
SDLT/DLT, or 30 remov-
able (all LTO)
>2.86TB, (all SDLT), or
3.00TB (all LTO), or
1.04TB (all DLT 8000)
>79.2GB/hr. (all SDLT), or
115.2GB/hr. (LTO), or
43.2GB/hr. (all DLT 8000)
<10 seconds, approximate,
Excluding Elevator Assem-
bly access
<10 seconds, approximate,
Excluding Elevator Assem-
bly access
Neo Series™ 2000
>250,000 hours
Excluding power supply,
tape drives, and cooling
fans
2,000,000 cartridge cycles
7 yrs. @ 30% duty cycle
<10 min (most FRU's)
8.75 in. (22.25) nominal
(5U)
Note: Rear rack enclosure
door (if any) must provide
minimum of 3.0" additional
clearance, from rear of
chassis, for SCSI cables
and fan housings.
16.75 in. (22.23 cm)
31.0 in. (78.74 cm)
Neo Series 4000
LVD/SE
0, 2, 4
Quantum SDLT and DLT
8000, LTO Ultrium 200
52 removable (all
SDLT/DLT, or 60 remov-
able (all LTO)
>5.72TB, (all SDLT), or
6.00TB (all LTO),
or2.08TB (all DLT 8000)
>158GB/hr. (all SDLT), or
230.4GB/hr. (LTO), or
86.4GB/hr. (all DLT 8000)
<10 seconds, approximate,
Excluding Elevator Assem-
bly access
<10 seconds, approximate,
Excluding Elevator Assem-
bly access
Neo Series™ 4000
>250,000 hours
Excluding power supply,
tape drives, and cooling
fans
2,000,000 cartridge cycles
7 yrs. @ 30% duty cycle
<10 min (most FRU's)
17.5 in. (44.50 cm) nominal
(10U)
Note: Rear rack enclosure
door (if any) must provide
minimum of 3.0" addi-
tional clearance, from rear
of chassis, for SCSI cables
and fan housings.
16.7 in. (42.4 cm)
31.0 in. (78.74 cm)
t
A-1
