CDM-625 Advanced Satellite Modem
Appendix F

F.5 ODU Operations via the CDM-625 Telnet Command Line Interface (CLI)

Appendix E. TELNET COMMAND LINE INTERFACE (CLI) OPERATION
The Telnet Command Line Interface (referred to hereafter as the Telnet CLI or the CLI) (Figure
F-15) is an Ethernet-based user menu system for the CDM-625 Advanced Satellite Modem
equipped with an installed and enabled optional IP Packet Processor card. The CLI facilitates
configuration, monitoring, and control of a CSAT-5060 Transceiver (ODU), installed in standalone
or 1:1 Redundancy configurations, using a user-supplied terminal emulator.
1. The CDM-625 Telnet Command Line Interface (CLI) is accessible only when the
2. The CDM-625 Telnet CLI uses Telnet TCP Port 107. Be sure to specify this port
3. For best results Comtech EF Data recommends PuTTY or Tera Term as the
4. The Telnet CLI's Remote Access Mode must be set to [Ethernet] in order to use

Figure F-15. CDM-625 Telnet Command Line Interface (CLI)

optional IP Packet Processor is installed and enabled.
when configuring your terminal emulator for CLI operation.
preferred terminal emulators.
the Telnet CLI for ODU operations.
(Left) Tera Term CLI Example
(Right) PuTTY CLI Example
F–54
Revision 13
MN-CDM625
