CDM-750 Advanced High-Speed Trunking Modem
Serial-based Remote Product Management
7.5.8

Bulk Configuration Strings

Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Global MGC= 245 bytes,
Configuration numerical
entries, fixed
values and
delimiters
Description of Arguments
Command or Query.
Set or return Global Configuration of CDM-750, in the form shown in the 'Response to Query' column, where:
FFFF.FFFF=Tx Frequency
SSSSSS.SSS=TX Symbol Rate
MM=Tx MODCOD
B=Tx Framing Mode
V=Tx Spectrum Inversion
A=Tx Alpha Rolloff
GGGGGG=Tx Gold Code
T=Tx Pilot
L=Tx Pilot Location
sPP.P=Tx Power Level
X=Tx Carrier State
ffff.ffff=Rx Frequency
ssssss.sss=Rx Symbol Rate
mm=Rx MODCOD
b=Rx Framing Mode
v=Rx Spectrum Inversion
a=Rx Alpha Rolloff
gggggg=Rx Gold Code
ee.e=Es/No Alarm Point
bbb=WAN Buffer Length
r=External Reference Frequency Selection
c=Enable Payload Compression
d=Learning and Aging
f=Flow Control
1=GigE Port 1 Control
2=GigE Port 2 Control
i=in band signaling control
r=LNB Reference Enable
p=LNB DC Power Supply Control
3=Opt Eth Port Control
x=(spare)
w=CnC mode
BBBCCC=CnC search delays
CCC=LNB High Current Limit Value
xx=(spare)
DDddEee=ACM Operating Parameters
HHhhJJjj=ACM Degradation Configuration
III=LNB Low Current Limit Value
same as TFQ
same as TSR
same as TMC
same as TFM
same as TSI
same as TAR
same as TGS
same as TPI
same as TLP
same as TPL
same as TXO
same as RFQ
same as RSR
same as RMC
same as RFM
same as RSI
same as RAR
same as RGS
same as EBA
same as WBL
same as EFR
same as EPC
same as LRN
same as GFC
same as LC1
same as LC2
same as SLC
–
–
–
–
same as CNM
same as CSD
same as LNH
–
same as ACM
same as ADC
same as LNL
7–30
Revision 2
MN-CDM750
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
MGC= MGC? MGC=FFFF.FFFFSS
MGC? SSSS.SSSMMBVAG
MGC* GGGGGTLsPP.PXfff
MGC# f.ffffssssss.sssmmbv
aggggggee.ebbbrcdf
12ixxxxwBBBCCCxx
xxxDDddEeeHHhhJJ
jjxxxxxTeeeeeeeeee
eeeeeeeeeeeeeeee
eeeeeeeeeexxxxxxx
xxxuuu.uuu.uuu.uuu.
uuvvv.vvv.vvv.vvvG
Hxxxxx11111111111
1111111112222222
2222222222222
(see Description of
Arguments for
details)
