Parameter Descriptions
15-89 Configuration Change Counter
Range:
0
*
3 3
3.15.11 15-9* Parameter Info
15-92 Defined Parameters
Range:
0
*
15-93 Modified Parameters
Range:
0
*
15-98 Drive Identification
Range:
0
*
15-99 Parameter Metadata
Range:
0
*

3.16 Parameters: 16-** Data Readouts

3.16.1 16-0* General Status
16-00 Control Word
Range:
0
*
16-01 Reference [Unit]
Range:
0 Referen-
ceFeedback 999999
Unit Reference-
*
FeedbackUnit]
250
Function:
NOTICE
[0 - 65535 ]
This parameter cannot be
adjusted while the motor is
running.
Function:
[0 - 9999 ] View a list of all defined parameters
in the frequency converter. The list
ends with 0.
Function:
[0 - 9999 ] View a list of the parameters that
have been changed from their
default setting. The list ends with 0.
Changes may not be visible until
up to 30 s after implementation.
Function:
[0 - 40 ] This parameter contains data used
by the MCT 10 Set-up Software.
Function:
[0 - 9999 ] This parameter contains data used
by the MCT 10 Set-up Software.
Function:
[0 - 65535 ] View the control word sent from
the frequency converter via the
serial communication port in hex
code.
Function:
[-999999 - View the present reference value
applied on impulse or analog basis
in the unit resulting from the
configuration selected in
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
16-01 Reference [Unit]
Range:
16-02 Reference %
Range:
0 %
*
16-03 Status Word
Range:
0
*
16-05 Main Actual Value [%]
Range:
0 %
*
16-06 Actual Position
Range:
0 Custom-
ReadoutUni
t2
*
16-07 Target Position
Range:
0 Custom-
ReadoutUni
t2
*
Function:
parameter 1-00 Configuration Mode
(Hz, Nm, or RPM).
Function:
[-200 - View the total reference. The total
200 %] reference is the sum of digital,
analog, preset, bus, and freeze
references, plus catch up and slow
down.
Function:
[0 - 65535 ] View the status word sent from the
frequency converter via the serial
communication port in hex code.
Function:
[-100 - View the 2-byte word sent with the
100 %] status word to the fieldbus master
reporting the main actual value.
Function:
[-2000000000 Shows the actual position in
- 2000000000 position units defined in parameter
CustomRea- group 17-7* Position Scaling. The
doutUnit2] value is based on the encoder
feedback in closed loop or on the
angle calculated by the motor
control in open loop. For
information about configuring the
readouts, see chapter 3.17.5 17-7*
Position Scaling.
Function:
NOTICE
[-2000000000
- 2000000000
This parameter is only valid
CustomRea-
with software version 48.XX.
doutUnit2]
Shows the actual end target
position for the active positioning
command in position units. Position
units are defined in parameter
group 17-7* Position Scaling.
