Danfoss VLT AutomationDrive FC 301 Programming Manual page 226

Parameter Descriptions
13-51 SL Controller Event
Option:
[224] Position Error
3 3
[225] Position Limit
[226] Touch on
Target
[227] Touch
Activated
13-52 SL Controller Action
Option:
[0] DISABLED
[1] No action
[2] Select set-up 1 Changes the active set-up
224
®
VLT AutomationDrive FC 301/302
Function:
NOTICE
This option is available only
with software version 48.20
and newer.
The position error exceeds the
value in parameter 4-71 Maximum
Position Error for the time set in
parameter 4-72 Position Error
Timeout.
NOTICE
This option is available only
with software version 48.20
and newer.
The position is outside the limits
set in parameter 3-06 Minimum
Position and
parameter 3-07 Maximum Position.
NOTICE
This option is available only
with software version 48.20
and newer.
Target position is reached in touch
probe position mode.
NOTICE
This option is available only
with software version 48.20
and newer.
Touch probe positioning active. The
frequency converter monitors the
touch probe sensor input.
Function:
Select the action corresponding to
the SLC event. Actions are executed
when the corresponding event
(defined in parameter 13-51 SL
Controller 1 Event) is evaluated as
true.
(parameter 0-10 Active Set-up) to 1.
If the set-up is changed, it merges
with other set-up commands
coming from either the digital
inputs or via a fieldbus.
Danfoss A/S © 10/2019 All rights reserved.
13-52 SL Controller Action
Option: Function:
[3] Select set-up 2 Changes the active set-up
parameter 0-10 Active Set-up) to 2.
If the set-up is changed, it merges
with other set-up commands
coming from either the digital
inputs or via a fieldbus.
[4] Select set-up 3 Changes the active set-up
(parameter 0-10 Active Set-up) to 3.
If the set-up is changed, it merges
with other set-up commands
coming from either the digital
inputs or via a fieldbus.
[5] Select set-up 4 Changes the active set-up
(parameter 0-10 Active Set-up) to 4.
If the set-up is changed, it merges
with other set-up commands
coming from either the digital
inputs or via a fieldbus.
[10] Select preset Selects preset reference 0.
ref 0 If the active preset reference is
changed, it merges with other
preset reference commands coming
from either the digital inputs or via
a fieldbus.
[11] Select preset Selects preset reference 1.
ref 1 If the active preset reference is
changed, it merges with other
preset reference commands coming
from either the digital inputs or via
a fieldbus.
[12] Select preset Selects preset reference 2.
ref 2 If the active preset reference is
changed, it merges with other
preset reference commands coming
from either the digital inputs or via
a fieldbus.
[13] Select preset Selects preset reference 3.
ref 3 If the active preset reference is
changed, it merges with other
preset reference commands coming
from either the digital inputs or via
a fieldbus.
[14] Select preset Selects preset reference 4.
ref 4 If the active preset reference is
changed, it merges with other
preset reference commands coming
from either the digital inputs or via
a fieldbus.
[15] Select preset Selects preset reference 5.
ref 5 If the active preset reference is
changed, it merges with other
preset reference commands coming
