Parameter Descriptions
0-12 This Set-up Linked to
Option: Function:
When completed,
parameter 0-13 Readout: Linked Set-
ups reads {1,2} to indicate that all
not changeable during operation-
parameters are now the same in
set-up 1 and set-up 2. If there are
changes to a not changeable during
operation-parameter, for example
parameter 1-30 Stator Resistance (Rs),
in set-up 2, they are also changed
automatically in set-up 1. A switch
between set-up 1 and set-up 2
during operation is now possible.
[0] Not linked
*
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 [0 - 255 ] View a list of all the set-ups linked
*
by parameter 0-12 This Set-up Linked
to. The parameter has 1 index for
each parameter set-up. The value
for each index shows which set-ups
are linked to that parameter set-up.
Index
0
1
2
3
4
Table 3.1 Set-up Link Example
0-14 Readout: Edit Set-ups / Channel
Range: Function:
0 [-2147483648 View the setting of
*
- parameter 0-11 Edit Set-up for each
2147483647 ] of the 4 different communication
channels. When the number is
shown as a hex number, as it is in
the LCP, each number represents 1
channel.
Numbers 1–4 represent a set-up
number; F means factory setting;
and A means active set-up. The
channels are, from right to left: LCP,
FC bus, USB, HPFB1-5.
M0013101
Programming Guide
0-14 Readout: Edit Set-ups / Channel
Range:
0-15 Readout: actual setup
Range:
0
*
3.1.3 0-2* LCP Display
Define the variables shown in the LCP.
NOTICE
For information on how to write display texts, refer to:
LCP value
{0}
{1,2}
{1,2}
{3}
0-20 Display Line 1.1 Small
{4}
Option:
[0]
[9]
[15]
[37]
[38]
[39]
[89]
[748]
[953]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Example: The number AAAAAA21h
means the following:
•
•
•
Function:
[0 - 255 ] Makes it possible to read out the
active set-up, also when [9] Multi
set-up is selected in
parameter 0-10 Active Set-up.
•
Parameter 0-37 Display Text 1.
•
Parameter 0-38 Display Text 2.
•
Parameter 0-39 Display Text 3.
Function:
Select a variable for display in line
1, left position.
None No display value selected.
Performance
Monitor
Readout:
actual setup
Display Text 1
Display Text 2
Display Text 3
Date and Time
Readout
PCD Feed
Forward
Profibus
Warning Word
The frequency converter
received the setting set-up
2 via a fieldbus channel.
This selection is reflected
in parameter 0-11 Edit Set-
up.
A user selected set-up 1
via the LCP.
All other channels are
using the active set-up.
27
3 3
