Parameter Descriptions
1-84 Precise Stop Counter Value
Range:
3 3
1-85 Precise Stop Speed Compensation Delay
Range:
10 ms
*
1-89 Stop Func Torque Ramp Time
Range:
0.01 s
*
3600.00 s]
3.2.12 1-9* Motor Temperature
1-90 Motor Thermal Protection
Option:
72
Function:
NOTICE
Not used for selections [0]
Precise ramp stop and [3] Speed
comp stop in
parameter 1-83 Precise Stop
Function.
Function:
[0 - 100 ms] Enter the delay time for sensors,
PLCs, and so on for use in
parameter 1-83 Precise Stop Function.
In speed–compensated stop mode,
the delay time at different
frequencies has a major influence
on the stop function.
NOTICE
Not used for selections [0]
Precise ramp stop, [1] Cnt stop
with reset, and [2] Cnt stop w/o
reset in parameter 1-83 Precise
Stop Function.
Function:
[0.01 - Configure the time in seconds
during which the torque is ramped
to 0, after the motor speed is
ramped down to the minimum
speed as specified in
parameter 1-81 Min Speed for
Function at Stop [RPM].
Function:
Motor thermal protection can be
implemented using a range of
techniques:
•
Via a PTC sensor in the
motor windings connected
to 1 of the analog or
digital inputs
(parameter 1-93 Thermistor
Resource). See
