Danfoss VLT AutomationDrive FC 301 Programming Manual page 205

Parameter Descriptions
13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option: Function:
[42] Auto-reset Trip An auto reset is performed.
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available on
the graphical LCP.
[45] Left key [◄] is pressed. Only available on the
graphical LCP.
[46] Right key [►] is pressed. Only available on the
graphical LCP.
▲
[47] Up key
[
graphical LCP.
▼
[48] Down key
[
graphical LCP.
[50] Comparator 4 Use the result of comparator 4.
[51] Comparator 5 Use the result of comparator 5.
[60] Logic rule 4 Use the result of logic rule 4.
[61] Logic rule 5 Use the result of logic rule 5.
[76] Digital input
Use the value of x30/2 (VLT
x30/2
General Purpose I/O MCB 101).
[77] Digital input
Use the value of x30/3 (VLT
x30/3
General Purpose I/O MCB 101).
[78] Digital input
Use the value of x30/4 (VLT
x30/4
General Purpose I/O MCB 101).
[79] Digital input
Use the value of x46/1 (VLT
x46/1
Extended Relay Card MCB 113).
[80] Digital input
Use the value of x46/3 (VLT
x46/3
Extended Relay Card MCB 113).
[81] Digital input
Use the value of x46/5 (VLT
x46/5
Extended Relay Card MCB 113).
[82] Digital input
Use the value of x46/7 (VLT
x46/7
Extended Relay Card MCB 113).
[83] Digital input
Use the value of x46/9 (VLT
x46/9
Extended Relay Card MCB 113).
[84] Digital input
Use the value of x46/11 (VLT
x46/11
Extended Relay Card MCB 113).
[85] Digital input
Use the value of x46/13 (VLT
x46/13
Extended Relay Card MCB 113).
[94] RS Flipflop 0 See parameter group 13-1*
Comparators.
[95] RS Flipflop 1 See parameter group 13-1*
Comparators.
M0013101
Programming Guide
] is pressed. Only available on the
] is pressed. Only available on the
®
®
®
®
®
®
®
®
®
®
Danfoss A/S © 10/2019 All rights reserved.
13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option: Function:
[96] RS Flipflop 2 See parameter group 13-1*
Comparators.
[97] RS Flipflop 3 See parameter group 13-1*
Comparators.
[98] RS Flipflop 4 See parameter group 13-1*
Comparators.
[99] RS Flipflop 5 See parameter group 13-1*
Comparators.
[100] RS Flipflop 6 See parameter group 13-1*
Comparators.
[101] RS Flipflop 7 See parameter group 13-1*
Comparators.
[222] Homing Ok
[223] On Target
[224] Position Error
[225] Position Limit
[226] Touch on
Target
[227] Touch
Activated
13-02 Stop Event
Select the boolean (true or false) input to deactivate smart logic
control.
Option: Function:
[0] False For descriptions of options [0]
False–[61] Logic rule 5, see
parameter 13-01 Start Event.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
[11] Below speed
low
[12] Above speed
high
[13] Out of feedb.
range
[14] Below feedb.
low
3 3
203
