Danfoss VLT AutomationDrive FC 301 Programming Manual page 36

Parameter Descriptions
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position. The options
are the same as those listed for parameter 0-20 Display Line 1.1
Small.
Option:
3 3
[1837] Temp. Input
X48/4
[1838] Temp. Input
X48/7
[1839] Temp. Input
X48/10
[1840] Analog Input
X49/1
[1841] Analog Input
X49/3
[1842] Analog Input
X49/5
[1843] Analog Out
X49/7
[1844] Analog Out
X49/9
[1845] Analog Out
X49/11
[1846] X49 Digital
Output [bin]
[1860] Digital Input 2
[1870] Mains Voltage
[1871] Mains
Frequency
[1872] Mains
Imbalance
[1875] Rectifier DC
Volt.
[1890] Process PID
Error
[1891] Process PID
Output
[1892] Process PID
Clamped
Output
[1893] Process PID
Gain Scaled
Output
[2316] Maintenance
Text
[3019] Wobble Delta
Freq. Scaled
[3110] Bypass Status
Word
[3111] Bypass
Running Hours
[3401] PCD 1 Write
to MCO
[3402] PCD 2 Write
to MCO
34
®
VLT AutomationDrive FC 301/302
Function:
Danfoss A/S © 10/2019 All rights reserved.
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position. The options
are the same as those listed for parameter 0-20 Display Line 1.1
Small.
Option: Function:
[3403] PCD 3 Write
to MCO
[3404] PCD 4 Write
to MCO
[3405] PCD 5 Write
to MCO
[3406] PCD 6 Write
to MCO
[3407] PCD 7 Write
to MCO
[3408] PCD 8 Write
to MCO
[3409] PCD 9 Write
to MCO
[3410] PCD 10 Write
to MCO
[3421] PCD 1 Read
from MCO
[3422] PCD 2 Read
from MCO
[3423] PCD 3 Read
from MCO
[3424] PCD 4 Read
from MCO
[3425] PCD 5 Read
from MCO
[3426] PCD 6 Read
from MCO
[3427] PCD 7 Read
from MCO
[3428] PCD 8 Read
from MCO
[3429] PCD 9 Read
from MCO
[3430] PCD 10 Read
from MCO
[3440] Digital Inputs
[3441] Digital
Outputs
[3450] Actual Position
[3451] Commanded
Position
[3452] Actual Master
Position
[3453] Slave Index
Position
[3454] Master Index
Position
[3455] Curve Position
[3456] Track Error
