Parameter Descriptions
16-31 System Temp.
Range:
Function:
NOTICE
0 °C
[-128 -
*
127 °C]
Valid for FC 302 only.
Shows the highest internal system
temperature. In the smaller
enclosure sizes (A–C), the system
temperature matches the control
card temperature measurement in
parameter 16-39 Control Card Temp.
In the larger enclosure sizes (D–F),
the system temperature is the
highest temperature measured on
hardware components with
temperature sensors, for example,
the power card(s).
16-32 Brake Energy /s
Range:
Function:
0 kW
[0 - 10000
View the brake power transmitted
*
kW]
to an external brake resistor, stated
as an instant value.
16-33 Brake Energy Average
Range:
Function:
0 kW
[0 - 10000
View the brake power transmitted
*
kW]
to an external brake resistor. The
mean power is calculated on an
average level based on the selected
time period within
parameter 2-13 Brake Power
Monitoring.
16-34 Heatsink Temp.
Range:
Function:
0 °C
[0 - 255 °C]
View the frequency converter heat
*
sink temperature. The cutout limit is
90 ±5 °C (194 ±9 °F), and the
motor cuts back in at 60 ±5 °C (140
±9 °F).
16-35 Inverter Thermal
Range:
Function:
0 %
[0 - 100 %]
View the percentage load on the
*
inverter.
16-36 Inv. Nom. Current
Range:
Function:
Size
[0.01 - 10000
View the inverter nominal current,
related
A]
which must match the nameplate
*
data on the connected motor. The
data is used for calculation of
M0013101
Programming Guide
16-36 Inv. Nom. Current
Range:
16-37 Inv. Max. Current
Range:
Size
related
*
16-38 SL Controller State
Range:
0
*
16-39 Control Card Temp.
Range:
0 °C
*
16-40 Logging Buffer Full
Option:
[0]
*
[1]
16-41 Performance Measurements
Range:
0
*
16-42 Service Log Counter
Range:
0
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
torque, motor overload protection,
and so on.
Function:
[0.01 - 10000
View the inverter maximum current,
A]
which must match the nameplate
data on the connected motor. The
data is used for calculation of
torque, motor overload protection,
and so on.
Function:
[0 - 100 ]
View the state of the event under
execution by the SL controller.
Function:
[0 - 100 °C]
View the temperature on the
control card, stated in °C.
Function:
View whether the logging buffer is
full (see chapter 3.15.2 15-1* Data
Log Settings). The logging buffer is
never full when
parameter 15-13 Logging Mode is set
to [0] Log always.
No
Yes
Function:
[0 -
2147483647 ]
Function:
[ 0 - 24 ]
Shows the number of service logs
stored in the ServiceLog file. If the
ServiceLog file is full, clear the
logged data by selecting option [5]
Clear service logs in
parameter 14-22 Operation Mode.
The logged data is deleted on the
next power-up.
3
3
253
