Danfoss VLT AutomationDrive FC 301 Programming Manual page 127

Parameter Descriptions
5-12 Terminal 27 Digital Input
Functions are described in parameter group 5-1* Digital Inputs.
Option: Function:
[233] Power Limit
Both
[234] Light Load
+Evacuation
5-13 Terminal 29 Digital Input
Select the function from the available digital input range and the
additional options [60] Counter A, [61] Counter A, [63] Counter B,
and [64] Counter B. Counters are used in smart logic control
functions.
Option: Function:
NOTICE
This parameter is available for
FC 302 only.
Functions are described in
parameter group 5-1* Digital Inputs.
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and
reset inv
[4] Quick stop
inverse
[5] DC-brake
inverse
[6] Stop inverse
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start
forward
[13] Enable start
reverse
[14] Jog
[15] Preset
reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze
reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select
bit 0
[24] Set-up select
bit 1
[28] Catch up
M0013101
Programming Guide
5-13 Terminal 29 Digital Input
Select the function from the available digital input range and the
additional options [60] Counter A, [61] Counter A, [63] Counter B,
and [64] Counter B. Counters are used in smart logic control
functions.
Option:
[29]
[30]
[31]
[32]
[34]
[35]
[44]
[51]
[55]
[56]
[57]
[58]
[60]
[61]
[62]
[63]
[64]
[65]
[70]
[71]
[72]
[73]
[74]
[75]
[78]
[80]
[91]
[92]
[94]
[95]
[96]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Slow down
Counter input
Pulse edge
triggered
Pulse time
based
Ramp bit 0
Ramp bit 1
Restart Drive
External
Interlock
DigiPot
increase
DigiPot
decrease
DigiPot clear
DigiPot Hoist
Counter A (up)
Counter A
(down)
Reset Counter
A
Counter B (up)
Counter B
(down)
Reset Counter
B
Mech. Brake
Feedb.
Mech. Brake
Feedb. Inv.
PID error
inverse
PID reset I
part
PID enable
MCO Specific
Reset Maint.
Word
PTC Card 1
Profidrive
OFF2
Profidrive
OFF3
Light Load
Detection
Evacuation
mode
Mains Loss
3 3
