Parameter Descriptions
5-13 Terminal 29 Digital Input
Select the function from the available digital input range and the
additional options [60] Counter A, [61] Counter A, [63] Counter B,
and [64] Counter B. Counters are used in smart logic control
functions.
3 3
Option:
[97] Mains Loss
Inverse
[98] Start edge
triggered
[100] Safe Option
Reset
[106] Set Master
Home
[107] Target Inverse
[108] Enable Mast.
Offset
[109] Enable Vir.
Master
[110] Start Homing
[111] Activate Touch
[112] Relative
Position
[113] Enable
Reference
[114] Sync. to Pos.
Mode
[115] Home Sensor
[116] Home Sensor
Inv.
[117] Touch Sensor
[118] Touch Sensor
Inv.
[119] Speed Mode
[122] Position Vir.
Master
[123] Master Marker
[124] Master Marker
Inv.
[125] Follower
Marker
[126] Follow. Marker
Inv.
[231] Power Limit
Mot.
[232] Power Limit
Gen.
[233] Power Limit
Both
[234] Light Load
+Evacuation
126
®
VLT AutomationDrive FC 301/302
Function:
Danfoss A/S © 10/2019 All rights reserved.
5-14 Terminal 32 Digital Input
Option: Function:
Select the function from the
available digital input range.
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and
reset inv
[4] Quick stop
inverse
[5] DC-brake
inverse
[6] Stop inverse
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start
forward
[13] Enable start
reverse
[14] Jog
[15] Preset
reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze
reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select
bit 0
[24] Set-up select
bit 1
[28] Catch up
[29] Slow down
[34] Ramp bit 0
[35] Ramp bit 1
[44] Restart Drive
[51] External
Interlock
[55] DigiPot
increase
[56] DigiPot
decrease
[57] DigiPot clear
[58] DigiPot Hoist
[62] Reset Counter
A
[65] Reset Counter
B
