Parameter Descriptions
6-55 Analog Output Filter
Option:
3 3
[0] Off
*
[1] On
3.7.7 6-6* Analog Output 2 MCB 101
Analog outputs are current outputs: 0/4–20 mA. Common
terminal (terminal X30/8) is the same terminal and
electrical potential for analog common connection.
Resolution on analog output is 12 bit.
6-60 Terminal X30/8 Output
Option:
[0] No operation
[52] MCO 0-20mA/
0-10V
[100] Output
frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to
limit
[105] Torq relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] PID Clamped
Output
[119] Torque % lim
168
®
VLT AutomationDrive FC 301/302
Function:
The following readout parameters
from selection in
parameter 6-50 Terminal 42 Output
have a filter selected when
parameter 6-55 Analog Output Filter
is on:
Selection 0–20 4–20
mA mA
Motor current [103] [133]
(0–I )
max
Torque limit (0– [104] [134]
T )
lim
Rated torque (0– [105] [135]
T )
nom
Power (0–P ) [106] [136]
nom
Speed (0– [107] [137]
Speed )
max
Table 3.25 Readout Parameters
Filter off.
Filter on.
Function:
Danfoss A/S © 10/2019 All rights reserved.
6-60 Terminal X30/8 Output
Option: Function:
[130] Output freq.
4-20mA
[131] Reference
4-20mA
[132] Feedback
4-20mA
[133] Motor cur.
4-20mA
[134] Torq.% lim
4-20 mA
[135] Torq.% nom
4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
[138] Torque
4-20mA
[139] Bus ctrl. 0-20
mA
[140] Bus ctrl. 4-20
mA
[141] Bus ctrl
0-20mA t.o.
[142] Bus ctrl
4-20mA t.o.
[149] Torque % lim
4-20mA
[150] Max Out Fr
4-20mA
6-61 Terminal X30/8 Min. Scale
Range: Function:
0 % [0 - 200 %] Scales the minimum output of the
*
selected analog signal on terminal
X30/8. Scale the minimum value as
a percentage of the maximum
signal value. For example, enter the
value 25% if the output should be
0 mA at 25% of the maximum
output value. The value can never
exceed the corresponding setting in
parameter 6-62 Terminal X30/8 Max.
Scale if the value is below 100%.
This parameter is active when VLT
General Purpose I/O MCB 101 is
mounted in the frequency
converter.
6-62 Terminal X30/8 Max. Scale
Range: Function:
100 % [0 - 200 %] Scales the maximum output of the
*
selected analog signal on terminal
X30/8. Scale the value to the
required maximum value of the
®
