Parameter Descriptions
8-46 BTM Transaction Status
Option:
[8] SO Config
Check Done
3 3
8-47 BTM Timeout
Range:
60 s
*
8-48 BTM Maximum Errors
Range:
21
*
8-49 BTM Error Log
Range:
0.255
*
9999.255 ]
3.9.5 8-5* Digital/Bus
Parameters for configuring the control word merging.
NOTICE
These parameters are active only when
parameter 8-01 Control Site is set to [0] Digital and control
word.
8-50 Coasting Select
Select the trigger for the coasting function.
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
198
Function:
Function:
[1 - 360 s] Select the BTM timeout after a BTM
transaction has been started.
Timeout is between each acyclic
write of parameters.
Function:
[0 - 21 ] Selects the maximum allowed
number of bulk transfer mode
errors before aborting. If it is set to
maximum, there is no abort.
Function:
[0.000 - List of parameters that failed during
bulk transfer mode. The value after
the decimal break is the fault code
(255 stands for no error).
Function:
A digital input triggers the coasting
function.
A serial communication port or the
fieldbus triggers the coasting
function.
The fieldbus/serial communication
port and a digital input trigger the
coasting function.
The fieldbus/serial communication
port or a digital input triggers the
coasting function.
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
8-51 Quick Stop Select
Select the trigger for the quick stop function.
Option:
[0]
[1]
[2]
[3]
*
8-52 DC Brake Select
Select control of the DC brake via the terminals (digital input)
and/or via the fieldbus.
Option:
[0]
[1]
[2]
[3]
8-53 Start Select
Select the trigger for the start function.
Option:
[0]
[1]
[2]
[3]
*
8-54 Reversing Select
Select the trigger for the reversing function.
Option:
[0]
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
NOTICE
When parameter 1-10 Motor
Construction is set to [1] PM
non-salient SPM, only selection
[0] Digital input is available.
Digital input Activate a start command via a
digital input.
Bus Activate a start command via the
serial communication port or
fieldbus option.
Logic AND Activate a start command via the
fieldbus/serial communication port
and also via 1 of the digital inputs.
Logic OR Activate a start command via the
fieldbus/serial communication port
or via 1 of the digital inputs.
Function:
Digital input A digital input triggers the start
function.
Bus A serial communication port or the
fieldbus triggers the start function.
Logic AND The fieldbus/serial communication
port and a digital input trigger the
start function.
Logic OR The fieldbus/serial communication
port or a digital input triggers the
start function.
Function:
Digital input A digital input triggers the
reversing function.
