Danfoss VLT AutomationDrive FC 301 Programming Manual page 90

Parameter Descriptions
3-05 On Reference Window
Range:
3 3
3-06 Minimum Position
Range:
-100000
Custom- - 2147483647
ReadoutUni CustomRea-
t2 doutUnit2]
*
3-07 Maximum Position
Range:
100000
Custom- - 2147483647
ReadoutUni CustomRea-
t2 doutUnit2]
*
88
Function:
•
Speed mode: Speed
window for on reference
status.
•
Torque mode: Torque
window for on reference
status.
•
Position mode: Speed
window for on target
status. See also
parameter 3-08 On Target
Window.
Function:
NOTICE
[-2147483648
This parameter is only
available with software version
48.XX.
Enter the minimum position. This
parameter defines the position
range in linear axis mode
(parameter 17-76 Position Axis Mode)
and in the position limit function
(parameter 4-73 Position Limit
Function).
Function:
NOTICE
[-2147483648
This parameter is only
available with software version
48.XX.
Enter the maximum position. This
parameter defines the position
range in linear and axis modes
(parameter 17-76 Position Axis
Mode).
Position range limits:
•
Linear:
Parameter 3-06 Minimum
Position to
parameter 3-07 Maximum
Position.
•
Rotary: 0–
parameter 3-07 Maximum
Position.
The position limit function uses this
parameter (parameter 4-73 Position
Limit Function).
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
3-08 On Target Window
Range:
5 Custom-
ReadoutUni
t2
*
3-09 On Target Time
Range:
1 ms
*
3.4.2 3-1* References
Select the preset references. Select Preset ref. bit 0/1/2 [16],
[17], or [18] for the corresponding digital inputs in
parameter group 5-1* Digital Inputs.
3-10 Preset Reference
Array [8]
Range: 0-7
Range:
0 %
*
Function:
NOTICE
[0 -
2147483647
This parameter is only
CustomRea-
available with software version
doutUnit2]
48.XX.
The frequency converter considers
the positioning completed and
sends the on target signal when
the actual position is within
parameter 3-08 On Target Window
for the duration of
parameter 3-09 On Target Time and
the actual speed is less than
parameter 3-05 On Reference
Window.
Function:
NOTICE
[0 - 60000
ms]
This parameter is only
available with software version
48.XX.
Enter the time for evaluating the on
target window, see also
parameter 3-08 On Target Window.
Function:
[-100 - Enter up to 8 different preset
100 %] references (0–7) in this parameter,
using array programming. The
preset reference is stated as a
percentage of the value Ref
(parameter 3-03 Maximum
Reference). If a Ref
0 (parameter 3-02 Minimum
Reference) is programmed, the
preset reference is calculated as a
percentage of the full reference
range, that is on the basis of the
difference between Ref
Ref . Afterwards, the value is
MIN
added to Ref . When using preset
MIN
MAX
different from
MIN
and
MAX
M0013101
