Parameter Descriptions
3.3.5 2-3* Adv. Mech Brake
Parameter 2-30 Position P Start Proportional Gain to
parameter 2-33 Speed PID Start Lowpass Filter Time can be
set up for very smooth transition change from speed
3 3
control to position control during parameter 2-25 Brake
Release Time - the time when the load is transferred from
the mechanical brake to the frequency converter.
Parameter 2-30 Position P Start Proportional Gain to
parameter 2-33 Speed PID Start Lowpass Filter Time are
activated when parameter 2-28 Gain Boost Factor is set to 0.
See Illustration 3.20 for more information.
2-30 Position P Start Proportional Gain
Range:
0.0500
*
1.0000 ]
2-31 Speed PID Start Proportional Gain
Range:
0.0500
*
1.0000 ]
2-32 Speed PID Start Integral Time
Range:
20.0 ms
*
20000.0 ms]
2-33 Speed PID Start Lowpass Filter Time
Range:
2.0 ms
*
ms]
2-34 Zero Speed Position P Proportional Gain
Range:
0.0000
*
1.0000 ]

3.4 Parameters: 3-** Reference/Ramps

Parameters for handling of reference, definition of
limitations, and configuration of the reaction of the
frequency converter to changes.
3.4.1 3-0* Reference Limits
3-00 Reference Range
Option:
86
Function:
[0.0000 -
Function:
[0.0000 -
Function:
[1.0 -
Function:
[0.1 - 100.0
Function:
NOTICE
[0.0000 -
This parameter is available
only with software version
48.XX.
Enter the proportional gain for
position control at standstill in
speed mode.
Function:
Select the range of the reference
signal and the feedback signal.
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
3-00 Reference Range
Option:
[0]
[1]
3-01 Reference/Feedback Unit
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[10]
[12]
[20]
[21]
[22]
[23]
[24]
[25]
[30]
[31]
[32]
[33]
[34]
[40]
[41]
[45]
[60]
[70]
[71]
[72]
Function:
Signal values can be positive only,
or positive and negative. The
minimum limit may have a negative
value, unless [1] Speed closed loop
control or [3] Process is selected in
parameter 1-00 Configuration Mode.
Min - Max Select the range of the reference
signal and the feedback signal.
Signal values can be positive only,
or positive and negative. The
minimum limit may have a negative
value, unless [1] Speed closed loop
control or [3] Process is selected in
parameter 1-00 Configuration Mode.
-Max - +Max For both positive and negative
values (both directions, relative to
parameter 4-10 Motor Speed
Direction).
Function:
Select the unit to be used in
process PID control references and
feedbacks. Parameter 1-00 Configu-
ration Mode must be either [3]
Process or [8] Extended PID Control.
None
%
RPM
Hz
Nm
PPM
1/min
Pulse/s
l/s
l/min
l/h
m³/s
m³/min
m³/h
kg/s
kg/min
kg/h
t/min
t/h
m/s
m/min
m
°C
mbar
bar
Pa
