Parameter Descriptions
6-73 Terminal X45/1 Bus Control
Range: Function:
0 % [0 - 100 %] Holds the level of analog output 3
*
(terminal X45/1) if controlled by
bus.
6-74 Terminal X45/1 Output Timeout Preset
Range: Function:
0 % [0 - 100 %] Holds the preset level of analog
*
output 3 (terminal X45/1).
If there is a fieldbus timeout and a
timeout function is selected in
parameter 6-70 Terminal X45/1
Output, the output is preset to this
level.
3.7.9 6-8* Analog Output 4 MCB 113
Parameters for configuring the scaling and limits for analog
output 4, terminals X45/3 and X45/4. Analog outputs are
current outputs: 0/4 to 20 mA. Resolution on analog
output is 11 bit.
6-80 Terminal X45/3 Output
Option: Function:
Select the function of terminal
X45/3 as an analog current output.
[0] No operation Same selections available as for
parameter 6-70 Terminal X45/1
Output.
[52] MCO 0-20mA/
0-10V
[100] Output
frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to
limit
[105] Torq relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] PID Clamped
Output
[119] Torque % lim
[130] Output freq.
4-20mA
[131] Reference
4-20mA
[132] Feedback
4-20mA
M0013101
Programming Guide
6-80 Terminal X45/3 Output
Option:
[133]
[134]
[135]
[136]
[137]
[138]
[139]
[140]
[141]
[142]
[149]
[150]
6-81 Terminal X45/3 Min. Scale
Range:
0 %
*
6-82 Terminal X45/3 Max. Scale
Range:
100 %
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
Motor cur.
4-20mA
Torq.% lim
4-20 mA
Torq.% nom
4-20mA
Power 4-20mA
Speed 4-20mA
Torque
4-20mA
Bus ctrl. 0-20
mA
Bus ctrl. 4-20
mA
Bus ctrl
0-20mA t.o.
Bus ctrl
4-20mA t.o.
Torque % lim
4-20mA
Max Out Fr
4-20mA
Function:
[0 - 200 %] Scales the minimum output of the
selected analog signal on terminal
X45/3. Scale the minimum value as
a percentage of the maximum
signal value, for example, 0 mA (or
0 Hz) is required at 25% of the
maximum output value and 25% is
programmed. The value can never
exceed the corresponding setting in
parameter 6-82 Terminal X45/3 Max.
Scale if the value is below 100%.
This parameter is active when VLT
Extended Relay Card MCB 113 is
mounted in the frequency
converter.
Function:
[0 - 200 %] Scales the maximum output of the
selected analog signal on terminal
X45/3. Scale the value to the
required maximum value of the
current signal output. Scale the
output to give a lower current than
20 mA at full scale or 20 mA at an
output below 100% of the
maximum signal value. If 20 mA is
the required output current at a
value between 0–100% of the full-
3 3
®
