Parameter Descriptions
5-01 Terminal 27 Mode
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
[0] Input Defines terminal 27 as a digital
*
input.
[1] Output Defines terminal 27 as a digital
output.
5-02 Terminal 29 Mode
Option: Function:
NOTICE
This parameter is available for
FC 302 only.
[0] Input Defines terminal 29 as a digital
*
input.
[1] Output Defines terminal 29 as a digital
output.
3.6.2 5-1* Digital Inputs
The digital inputs are used for selecting various functions
in the frequency converter. Table 3.17 shows which
functions can be assigned to digital inputs.
Functions in group 1 have higher priority than functions in
group 2.
Group 1 Reset, coast stop, reset, and coast stop, quick stop,
DC brake, stop, and the [Off] key.
Group 2 Start, latched start, reversing, start reversing, jog,
and freeze output.
Table 3.16 Function Groups
Digital input function Select
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC brake inverse
Stop inverse
Start
Latched start
Reversing [10]
Start reversing [11]
Enable start forward [12]
M0013101
Programming Guide
Terminal
[0] All, terminal 32, 33
[1] All
[2] All, terminal 27
[3] All
[4] All
[5] All
[6] All
[8] All, terminal 18
[9] All
All, terminal 19
All
All
Danfoss A/S © 10/2019 All rights reserved.
Digital input function Select
Enable start reverse [13]
Jog [14]
Preset reference on [15]
Preset ref bit 0 [16]
Preset ref bit 1 [17]
Preset ref bit 2 [18]
Freeze reference [19]
Freeze output [20]
Speed up [21]
Speed down [22]
Set-up select bit 0 [23]
Set-up select bit 1 [24]
Precise stop inverse [26]
Precise start, stop [27]
Catch up [28]
Slow down [29]
Counter input [30]
Pulse input edge [31]
triggered
Pulse input time based [32]
Ramp bit 0 [34]
Ramp bit 1 [35]
Latched precise start [40]
Latched precise stop [41]
inverse
External interlock [51]
DigiPot increase [55]
DigiPot decrease [56]
DigiPot clear [57]
DigiPot hoist [58]
Counter A (up) [60]
Counter A (down) [61]
Reset counter A [62]
Counter B (up) [63]
Counter B (down) [64]
Reset counter B [65]
Mech. brake feedb. [70]
Mech. brake feedb. inv. [71]
PID error inv. [72]
PID reset I-part [73]
PID enable [74]
MCO specific [75]
PTC card 1 [80]
PROFIdrive OFF2 [91]
PROFIdrive OFF3 [92]
Light load detection [94]
Evacuation [95]
Mains loss [96]
Mains loss inverse [97]
Start edge triggered [98]
Safety option reset [100]
Enable master offset [108]
Start virtual master [109]
Terminal
All
All, terminal 29
All
All
3
All
All
All
All
All
All
All
All
18, 19
18, 19
All
All
29, 33
29, 33
29, 33
All
All
18, 19
18, 19
–
All
All
All
All
29, 33
29, 33
All
29, 33
29, 33
All
All
All
All
All
All
All
All
All
All
All
All
32, 33
32, 33
All
–
All
All
115
