Parameter Lists
5.2.27 42-** Safety Functions
Par. Parameter description
No. #
42-1* Speed Monitoring
42-10 Measured Speed Source
42-11 Encoder Resolution
42-12 Encoder Direction
42-13 Gear Ratio
42-14 Feedback Type
42-15 Feedback Filter
42-18 Zero Speed Timer
42-2* Safe Input
42-20 Safe Function
42-21 Type
42-22 Discrepancy Time
42-23 Stable Signal Time
42-24 Restart Behaviour
42-3* General
42-30 External Failure Reaction
42-31 Reset Source
42-33 Parameter Set Name
42-36 Level 1 Password
42-37 Level 1 Password Buffer
42-4* SS1
42-40 Type
42-41 Ramp Profile
42-42 Delay Time
42-43 Delta T
42-44 Deceleration Rate
42-45 Delta V
42-46 Zero Speed
42-47 Ramp Time
42-48 S-ramp Ratio at Decel. Start
42-49 S-ramp Ratio at Decel. End
42-5* SLS
42-50 Cut Off Speed
42-51 Speed Limit
42-52 Fail Safe Reaction
42-53 Start Ramp
42-54 Ramp Down Time
42-61 Destination Address
42-8* Status
42-80 Safe Option Status
42-81 Safe Option Status 2
42-85 Active Safe Func.
42-86 Safe Option Info
42-88 Supported Customization File Version
42-89 Customization File Version
42-9* Special
42-90 Restart Safe Option
Table 5.11
M0013101
Programming Guide
Default value 4-set-up
ExpressionLimit 1 set-up
1024 N/A 1 set-up
[0] Clockwise 1 set-up
1 N/A 1 set-up
[0] With direction info 1 set-up
200 Hz 1 set-up
8760 h 1 set-up
ExpressionLimit 1 set-up
[0] NCNC 1 set-up
10 ms 1 set-up
10 ms 1 set-up
[0] Manual 1 set-up
[0] STO 1 set-up
[0] Drive Reset 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
[0] Delay 1 set-up
[0] Linear 1 set-up
1 s 1 set-up
2 % 1 set-up
1500 /s 1 set-up
120 RPM 1 set-up
10 RPM 1 set-up
1 s 1 set-up
50 % 1 set-up
50 % 1 set-up
270 RPM 1 set-up
150 RPM 1 set-up
[0] STO 1 set-up
[0] No 1 set-up
1 s 1 set-up
1 N/A 1 set-up
0 N/A All set-ups
0 N/A 1 set-up
[10] None All set-ups
0 N/A All set-ups
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
[0] No All set-ups
