Parameter Descriptions
5-32 Term X30/6 Digi Out (MCB 101)
Option:
[82] SL digital
output C
[83] SL digital
3 3
output D
[84] SL digital
output E
[85] SL digital
output F
[90] kWh counter
pulse
[96] Reverse After
Ramp
[98] Virtual Master
Dir.
[120] Local ref
active
[121] Remote ref
active
[122] No alarm
[123] Start
command
activ
[124] Running
reverse
[125] Drive in hand
mode
[126] Drive in auto
mode
[151] ATEX ETR cur.
alarm
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur.
warning
[154] ATEX ETR freq.
warning
[180] Clock Fault
[181] Prev.
Maintenance
[188] AHF Capacitor
Connect
[189] External Fan
Control
[190] Safe Function
active
148
®
VLT AutomationDrive FC 301/302
Function:
Sends a pulse (200 ms pulse width)
to the output terminal whenever
kWh counter changes
(parameter 15-02 kWh Counter).
NOTICE
This option is available only
with software version 48.XX.
NOTICE
This option is available only
with software version 48.XX.
Danfoss A/S © 10/2019 All rights reserved.
5-32 Term X30/6 Digi Out (MCB 101)
Option: Function:
[191] Safe Opt.
Reset req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
[221] IGBT-cooling Use this option for handling the
overcurrent trips. When the
frequency converter detects an
overcurrent condition, it shows
alarm 13, Overcurrent and triggers a
reset. If the overcurrent condition
occurs the 3
frequency converter shows alarm
13, Overcurrent and initiates a 3-
minute delay before the next reset.
NOTICE
[222] Homing OK
This option is available only
with software version 48.XX.
NOTICE
[223] On Target
This option is available only
with software version 48.XX.
NOTICE
[224] Position Limit
This option is available only
with software version 48.XX.
NOTICE
[225] Position Error
This option is available only
with software version 48.XX.
NOTICE
[226] Touch on
Target
This option is available only
with software version 48.XX.
NOTICE
[227] Touch
Activated
This option is available only
with software version 48.XX.
[231] In Power Lim.
Mot.
[232] In Power Lim.
Gen.
[233] In Power Limit
rd
time in a row, the
