Danfoss VLT AutomationDrive FC 301 Programming Manual page 46

Parameter Descriptions
0-30 Unit for User-defined Readout
Option:
[178] kBar
[180] HP
3 3
0-31 Min Value of User-defined Readout
Range:
0 Custom-
ReadoutUni par. 0-32
t CustomRea-
*
doutUnit]
0-32 Max Value of User-defined Readout
Range:
100
Custom- 999999.99
ReadoutUni CustomRea-
t doutUnit]
*
0-33 Source for User-defined Readout
Option:
[105] Torq relate to
rated
[143] PID Clamped
Output
4-20mA
[240] Default Source
*
0-37 Display Text 1
Range:
0
*
44
Function:
Function:
[ -999999.99 - This parameter sets the minimum
value of the custom-defined
readout (occurs at 0 speed). Only
possible to set different from 0
when selecting a linear unit in
parameter 0-30 Unit for User-defined
Readout. For quadratic and cubic
units, the minimum value is 0.
Function:
[ par. 0-31 - This parameter sets the maximum
value to be shown when the speed
of the motor has reached the set
value for parameter 4-13 Motor
Speed High Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed Unit).
Function:
Enter the source of the user-defined
readout.
Function:
[0 - 25 ] Enter a text which can be viewed in
the graphical display by selecting
[37] Display Text 1 in
•
Parameter 0-20 Display Line
1.1 Small,
•
Parameter 0-21 Display Line
1.2 Small,
•
Parameter 0-22 Display Line
1.3 Small,
•
Parameter 0-23 Display Line
2 Large, or
•
Parameter 0-24 Display Line
3 Large.
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
0-38 Display Text 2
Range:
0
*
0-39 Display Text 3
Range:
0
*
3.1.5 0-4* LCP Keypad
Enable, disable, and password protect individual keys on
the LCP.
0-40 [Hand on] Key on LCP
Option:
[0]
[1]
[2]
Function:
[0 - 25 ] Enter a text which can be viewed in
the graphical display by selecting
[38] Display Text 2 in
•
Parameter 0-20 Display Line
1.1 Small,
•
Parameter 0-21 Display Line
1.2 Small,
•
Parameter 0-22 Display Line
1.3 Small,
•
Parameter 0-23 Display Line
2 Large, or
•
Parameter 0-24 Display Line
3 Large.
Function:
[0 - 25 ] Enter a text which can be viewed in
the graphical display by selecting
[39] Display Text 3 in
•
Parameter 0-20 Display Line
1.1 Small,
•
Parameter 0-21 Display Line
1.2 Small,
•
Parameter 0-22 Display Line
1.3 Small,
•
Parameter 0-23 Display Line
2 Large, or
•
Parameter 0-24 Display Line
3 Large.
Function:
Disabled No effect when [Hand On] is
pressed. Select [0] Disabled to avoid
accidental start of the frequency
converter in hand-on mode.
Enabled The LCP switches to hand-on mode
directly when [Hand On] is pressed.
Password After pressing [Hand On] a
password is required. If
parameter 0-40 [Hand on] Key on LCP
is included in My Personal Menu,
define the password in
parameter 0-65 Personal Menu
Password. Otherwise define the
