Danfoss VLT AutomationDrive FC 301 Programming Manual page 289

Parameter Descriptions
33-12 Position Offset for Synchronization
Range: Function:
-
1073741824 ]
33-13 Accuracy Window for Position Sync.
Range: Function:
1000 [-1073741824
*
-
1073741823 ]
33-14 Relative Slave Velocity Limit
Range: Function:
0 % [0 - 100 %]
*
33-15 Marker Number for Master
Range: Function:
1 [1 - 10000 ]
*
33-16 Marker Number for Slave
Range: Function:
1 [1 - 10000 ]
*
33-17 Master Marker Distance
Range: Function:
4096 [0 -
*
1073741823 ]
33-18 Slave Marker Distance
Range: Function:
4096 [0 -
*
1073741823 ]
33-19 Master Marker Type
Option: Function:
[0] Encoder Z
*
positive
[1] Encoder Z
negative
[2] Ext. marker
positive
[3] Ext. marker
negative
33-20 Slave Marker Type
Option: Function:
[0] Encoder Z
*
positive
[1] Encoder Z
negative
[2] Ext. marker
positive
[3] Ext. marker
negative
M0013101
Programming Guide
33-21 Master Marker Tolerance Window
Range:
0
*
33-22 Slave Marker Tolerance Window
Range:
0
*
33-23 Start Behaviour for Marker Sync
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[1000]
[1001]
[1002]
[1003]
[1004]
[1005]
[1006]
[1007]
[2000]
33-24 Marker Number for Fault
Range:
10
*
33-25 Marker Number for Ready
Range:
1
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
[ 0 - par.
33-17 ]
Function:
[ 0 - par.
33-18 ]
Function:
Leading
marker
Following
marker
Closest marker
Master vel /
ldg mrk
Master vel /
flw mrk
Master vel /
cls mrk
Next 2
markers
Start with
poly5
Ldg mrk late
offs
Flw mrk late
offs
Cls mrk late
offs
Mv/ldg mrk/lt
off
Mv/flw mrk/lt
off
Mv/cls mrk/lt
off
Next 2 mrk/lt
off
Poly5 / late
offs
Camstart mast
mrk
Function:
[0 - 10000 ]
Function:
[0 - 10000 ]
3 3
287
