Parameter Descriptions
5-33 Term X30/7 Digi Out (MCB 101)
Option:
[84] SL digital
output E
[85] SL digital
3 3
output F
[90] kWh counter
pulse
[96] Reverse After
Ramp
[98] Virtual Master
Dir.
[120] Local ref
active
[121] Remote ref
active
[122] No alarm
[123] Start
command
activ
[124] Running
reverse
[125] Drive in hand
mode
[126] Drive in auto
mode
[151] ATEX ETR cur.
alarm
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur.
warning
[154] ATEX ETR freq.
warning
[180] Clock Fault
[181] Prev.
Maintenance
[188] AHF Capacitor
Connect
[189] External Fan
Control
[190] Safe Function
active
[191] Safe Opt.
Reset req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
[221] IGBT-cooling
[222] Homing OK
[223] On Target
150
®
VLT AutomationDrive FC 301/302
Function:
Danfoss A/S © 10/2019 All rights reserved.
5-33 Term X30/7 Digi Out (MCB 101)
Option: Function:
[224] Position Limit
[225] Position Error
[226] Touch on
Target
[227] Touch
Activated
[231] In Power Lim.
Mot.
[232] In Power Lim.
Gen.
[233] In Power Limit
3.6.4 5-4* Relays
Parameters for configuring the timing and the output
functions for the relays.
5-40 Function Relay
Option: Function:
Relay 1 [0], Relay 2 [1].
VLT
Relay 3 [2], Relay 4 [3], Relay 5 [4],
Relay 6 [5].
VLT
[6], Relay 8 [7], Relay 9 [8].
[0] No operation All digital and relay outputs are by
default set to No Operation.
[1] Control Ready The control card is ready, for
example: Feedback from a
frequency converter where the
control is supplied by an external
24 V supply (VLT
MCB 107) and the main power to
frequency converter is not detected.
[2] Drive ready The frequency converter is ready to
operate. Mains and control supplies
are OK.
[3] Drive rdy/rem The frequency converter is ready for
ctrl operation and is in auto-on mode.
[4] Enable / no Ready for operation. No start or
warning stop commands have been applied
(start/disable). No warnings are
active.
[5] Running The motor is running, and shaft
torque is present.
[6] Running / no Output speed is higher than the
warning speed set in parameter 1-81 Min
Speed for Function at Stop [RPM].
The motor runs and there are no
warnings.
®
Extended Relay Card MCB 113:
®
Relay Card MCB 105: Relay 7
®
24 V DC Supply
M0013101
