Parameter Descriptions
36-51 Terminal X49/9 Digital Output
Option:
[17] Above speed,
high
[18] Out of feedb.
3 3
range
[19] Below
feedback, low
[20] Above
feedback, high
[21] Thermal
warning
[22] Ready,no
thermal W
[23] Remote,ready,
no TW
[24] Ready, Voltage
OK
[25] Reverse
[26] Bus OK
[27] Torque limit &
stop
[28] Brake, no
brake war
[29] Brake ready,
no fault
[30] Brake fault
(IGBT)
[31] Relay 123
[32] Mech brake
ctrl
[33] Safe stop
active
[35] External
Interlock
[38] Motor
feedback error
[39] Tracking error
[40] Out of ref
range
[41] Below
reference, low
[42] Above ref,
high
[43] Extended PID
Limit
[45] Bus ctrl.
[46] Bus ctrl, 1 if
timeout
[47] Bus ctrl, 0 if
timeout
[50] On Reference
[51] MCO
controlled
[60] Comparator 0
302
®
VLT AutomationDrive FC 301/302
Function:
Danfoss A/S © 10/2019 All rights reserved.
36-51 Terminal X49/9 Digital Output
Option: Function:
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital
output A
[81] SL digital
output B
[82] SL digital
output C
[83] SL digital
output D
[84] SL digital
output E
[85] SL digital
output F
[90] kWh counter
pulse
[96] Reverse After
Ramp
[98] Virtual Master
Dir.
[120] Local ref
active
[121] Remote ref
active
[122] No alarm
[123] Start
command
activ
[124] Running
reverse
[125] Drive in hand
mode
[126] Drive in auto
mode
[151] ATEX ETR cur.
alarm
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur.
warning
[154] ATEX ETR freq.
warning
[180] Clock Fault
