Parameter Descriptions
3.8.4 7-1* Torque PI Control
Parameters for configuring the torque PI control.
7-10 Torque PI Feedback Source
Select the feedback source for the torque controller.
3 3
Option:
[0] Controller Off
*
[1] Analog Input
53
[2] Analog Input
54
[3] Estimed
Torque
7-12 Torque PI Proportional Gain
Range:
100 %
*
7-13 Torque PI Integration Time
Range:
0.020 s
*
7-16 Torque PI Lowpass Filter Time
Range:
5 ms
*
ms]
7-18 Torque PI Feed Forward Factor
Range:
0 %
*
7-19 Current Controller Rise Time
Range:
Size
related
*
178
Function:
Select to operate in open loop.
Select to use torque feedback from
the analog input.
Select to use torque feedback from
the analog input.
Select to use the torque feedback
estimated by the frequency
converter.
Function:
[0 - 500 %] Enter the proportional gain value
for the torque controller. Selection
of a high value makes the
controller react faster. Too high a
setting leads to controller
instability.
Function:
[0.002 - 2 s] Enter the integration time for the
torque controller. Selection of a low
value makes the controller react
faster. Too low a setting leads to
controller instability.
Function:
[0.1 - 100 Enter the time constant for the
torque control low-pass filter.
Function:
[0 - 100 %] Enter the torque feed forward
factor value. The reference signal
bypasses the torque controller by
this value.
Function:
[15 - 100 %] Enter the value for the rise time of
the current controller as a
percentage of the control period.
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
3.8.5 7-2* Process Ctrl. Feedb.
Select the feedback sources for the process PID control,
and how this feedback should be handled.
7-20 Process CL Feedback 1 Resource
Option:
[0]
*
[1]
[2]
[3]
[4]
[7]
[8]
[15]
[16]
[17]
[18]
7-22 Process CL Feedback 2 Resource
Option:
[0]
*
[1]
[2]
[3]
Function:
The effective feedback signal is
made up of the sum of up to 2
different input signals.
Select which frequency converter
input should be treated as the
st
source of the 1
nd
The 2 input signal is defined in
parameter 7-22 Process CL Feedback
2 Resource.
No function
Analog Input
53
Analog Input
54
Frequency
input 29
Frequency
input 33
Analog Input
X30/11
Analog Input
X30/12
Analog Input
X48/2
Analog Input
X49/1
Analog Input
X49/3
Analog Input
X49/5
Function:
The effective feedback signal is
made up of the sum of up to 2
different input signals. Select which
frequency converter input should
be treated as the source of the 2
of these signals. The 1
is defined in parameter 7-20 Process
CL Feedback 1 Resource.
No function
Analog Input
53
Analog Input
54
Frequency
input 29
of these signals.
nd
st input signal
M0013101
