Danfoss VLT AutomationDrive FC 301 Programming Manual page 35

Parameter Descriptions
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position. The options
are the same as those listed for parameter 0-20 Display Line 1.1
Small.
Option: Function:
[1646] Motor Phase V
Current
[1647] Motor Phase
W Current
[1648] Speed Ref.
After Ramp
[RPM]
[1650] External
Reference
[1651] Pulse
Reference
[1652] Feedback[Unit]
[1653] Digi Pot
Reference
[1657] Feedback
[RPM]
[1660] Digital Input
[1661] Terminal 53
Switch Setting
[1662] Analog Input
53
[1663] Terminal 54
Switch Setting
[1664] Analog Input
54
[1665] Analog Output
42 [mA]
[1666] Digital Output
[bin]
[1667] Freq. Input
#29 [Hz]
[1668] Freq. Input
#33 [Hz]
[1669] Pulse Output
#27 [Hz]
[1670] Pulse Output
#29 [Hz]
[1671] Relay Output
[bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop
Counter
[1675] Analog In
X30/11
[1676] Analog In
X30/12
[1677] Analog Out
X30/8 [mA]
M0013101
Programming Guide
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position. The options
are the same as those listed for parameter 0-20 Display Line 1.1
Small.
Option:
[1678]
[1679]
[1680]
[1681]
[1682]
[1683]
[1684]
[1685]
[1686]
[1687]
[1689]
[1690]
[1691]
[1692]
[1693]
[1694]
[1695]
[1696]
[1697]
[1698]
[1804]
[1820]
[1821]
[1823]
[1827]
[1828]
[1829]
[1836]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Analog Out
X45/1 [mA]
Analog Out
X45/3 [mA]
Fieldbus CTW
1
Fieldbus Sync.
REF
Fieldbus REF 1
Fieldbus Pos.
REF
Comm. Option
STW
FC Port CTW 1
FC Port REF 1
Bus Readout
Alarm/Warning
Configurable
Alarm/Warning
Word
Alarm Word
Alarm Word 2
Warning Word
Warning Word
2
Ext. Status
Word
Ext. Status
Word 2
Maintenance
Word
Alarm Word 3
Warning Word
3
Mech Brake
Count
Commanded
Position
Master
Position
Virtual Master
Pos.
Safe Opt. Est.
Speed
Safe Opt.
Meas. Speed
Safe Opt.
Speed Error
Analog Input
X48/2 [mA]
3 3
