Parameter Descriptions
6-62 Terminal X30/8 Max. Scale
Range: Function:
current signal output. Scale the
output to give a lower current than
20 mA at full scale or 20 mA at an
output below 100% of the
maximum signal value. If 20 mA is
the required output current at a
value between 0–100% of the full-
scale output, program the
percentage value in the parameter,
that is 50%=20 mA. If a current 4–
20 mA is required at maximum
output (100%), calculate the
percentage value as follows:
20 mA / desired maximum current x 100 %
i . e . 10 mA :
6-63 Terminal X30/8 Bus Control
Range: Function:
0 % [0 - 100 %] Holds the level of output X30/8 if
*
controlled by bus.
6-64 Terminal X30/8 Output Timeout Preset
Range: Function:
0 % [0 - 100 %] Holds the preset level of output
*
X30/8.
If there is a fieldbus timeout and a
timeout function is selected in
parameter 6-60 Terminal X30/8
Output, the output is preset to this
level.
3.7.8 6-7* Analog Output 3 MCB 113
Parameters for configuring the scaling and limits for analog
output 3, terminals X45/1, and X45/2. Analog outputs are
current outputs: 0/4–20 mA. Resolution on analog output
is 11 bit.
6-70 Terminal X45/1 Output
Option: Function:
Select the function of terminal
X45/1 as an analog current output.
[0] No operation When no signal on the analog
output is present.
[52] MCO 0-20mA/
0-10V
[100] Output 0 Hz = 0 mA; 100 Hz = 20 mA.
frequency
[101] Reference Parameter 3-00 Reference Range
[Min. - Max.] 0% = 0 mA; 100% =
20 mA.
M0013101
Programming Guide
20 − 4
x 100 = 160 %
10
Danfoss A/S © 10/2019 All rights reserved.
6-70 Terminal X45/1 Output
Option: Function:
Parameter 3-00 Reference Range [-
Max. - Max.] -100% = 0 mA; 0% =
10 mA; +100% = 20 mA.
[102] Feedback
[103] Motor Current The value is taken from
parameter 16-37 Inv. Max. Current.
The inverter maximum current
(160% current) is equal to 20 mA.
Example: Inverter normal current
(11 kW) = 24 A. 160% = 38.4 A.
Motor normal current = 22 A,
readout 11.46 mA.
20 mA x 22 A
38 . 4 A
In case the normal motor current is
equal to 20 mA, the output setting
of parameter 6-52 Terminal 42
Output Max Scale is:
I
VLT
I
Motor
[104] Torque rel to The torque setting is related to the
limit setting in parameter 4-16 Torque
Limit Motor Mode.
[105] Torq relate to The torque is related to the motor
rated torque setting.
[106] Power Taken from parameter 1-20 Motor
Power [kW].
[107] Speed Taken from
parameter 3-03 Maximum Reference.
20 mA = value in
parameter 3-03 Maximum Reference.
[108] Torque Torque reference related to 160%
torque.
[109] Max Out Freq In relation to parameter 4-19 Max
Output Frequency.
[113] PID Clamped
Output
[119] Torque % lim
[130] Output freq. 0 Hz = 4 mA, 100 Hz = 20 mA.
4-20mA
[131] Reference Parameter 3-00 Reference Range
4-20mA [Min.-Max.] 0% = 4 mA; 100% =
20 mA.
Parameter 3-00 Reference Range [-
Max-Max.] -100% = 4 mA; 0% = 12
mA; +100% = 20 mA.
[132] Feedback
4-20mA
[133] Motor cur. The value is taken from
4-20mA parameter 16-37 Inv. Max. Current.
= 11 . 46 mA
x 100
38 . 4 x 100
Max = = 175 %
22
Norm
169
