Danfoss VLT AutomationDrive FC 301 Programming Manual page 327

Parameter Lists
3-07 Maximum Position
3-08 On Target Window
3-09 On Target Time
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-12 Catch up/slow Down Value
3-13 Reference Site
3-14 Preset Relative Reference
3-15 Reference Resource 1
3-16 Reference Resource 2
3-17 Reference Resource 3
3-18 Relative Scaling Reference Resource
3-19 Jog Speed [RPM]
3-2* References 2
3-20 Preset Target
3-21 Touch Target
3-22 Master Scale Numerator
3-23 Master Scale Denominator
3-24 Master Lowpass Filter Time
3-25 Master Bus Resolution
3-26 Master Offset
3-27 Virtual Master Max Ref
3-28 Master Offset Speed Ref
3-4* Ramp 1
3-40 Ramp 1 Type
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-45 Ramp 1 S-ramp Ratio at Accel. Start
3-46 Ramp 1 S-ramp Ratio at Accel. End
3-47 Ramp 1 S-ramp Ratio at Decel. Start
3-48 Ramp 1 S-ramp Ratio at Decel. End
3-5* Ramp 2
3-50 Ramp 2 Type
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-55 Ramp 2 S-ramp Ratio at Accel. Start
3-56 Ramp 2 S-ramp Ratio at Accel. End
3-57 Ramp 2 S-ramp Ratio at Decel. Start
3-58 Ramp 2 S-ramp Ratio at Decel. End
3-6* Ramp 3
3-60 Ramp 3 Type
3-61 Ramp 3 Ramp up Time
3-62 Ramp 3 Ramp down Time
3-65 Ramp 3 S-ramp Ratio at Accel. Start
3-66 Ramp 3 S-ramp Ratio at Accel. End
3-67 Ramp 3 S-ramp Ratio at Decel. Start
3-68 Ramp 3 S-ramp Ratio at Decel. End
3-7* Ramp 4
3-70 Ramp 4 Type
3-71 Ramp 4 Ramp up Time
3-72 Ramp 4 Ramp Down Time
3-75 Ramp 4 S-ramp Ratio at Accel. Start
3-76 Ramp 4 S-ramp Ratio at Accel. End
3-77 Ramp 4 S-ramp Ratio at Decel. Start
M0013101
Programming Guide
100000 CustomRea-
doutUnit2 All set-ups
5 CustomReadoutUnit2 All set-ups
1 ms All set-ups
0 % All set-ups
ExpressionLimit All set-ups
0 % All set-ups
[0] Linked to Hand / Auto All set-ups
0 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[0] No function All set-ups
ExpressionLimit All set-ups
0 CustomReadoutUnit2 All set-ups
0 CustomReadoutUnit2 All set-ups
1 N/A All set-ups
1 N/A All set-ups
20 ms All set-ups
65536 N/A All set-ups
0 CustomReadoutUnit2 All set-ups
50.0 Hz All set-ups
1500 RPM All set-ups
[0] Linear All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
50 % All set-ups
50 % All set-ups
50 % All set-ups
50 % All set-ups
[0] Linear All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
50 % All set-ups
50 % All set-ups
50 % All set-ups
50 % All set-ups
[0] Linear All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
50 % All set-ups
50 % All set-ups
50 % All set-ups
50 % All set-ups
[0] Linear All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
50 % All set-ups
50 % All set-ups
50 % All set-ups
Danfoss A/S © 10/2019 All rights reserved.
TRUE 0 Int32
TRUE 0 Int32
TRUE -3 Uint16
TRUE -2 Int16
TRUE -1 Uint16
TRUE -2 Int16
TRUE - Uint8
TRUE -2 Int32
TRUE - Uint8
TRUE - Uint8
TRUE - Uint8
TRUE - Uint8
TRUE 67 Uint16
TRUE 0 Int32
TRUE 0 Int32
TRUE 0 Int32
TRUE 0 Int32
TRUE -4 Uint16
TRUE 0 Uint32
TRUE 0 Int32
TRUE -1 Uint16
TRUE 67 Uint16
TRUE - Uint8
TRUE -2 Uint32
TRUE -2 Uint32
TRUE 0 Uint8
TRUE 0 Uint8
TRUE 0 Uint8
TRUE 0 Uint8
TRUE - Uint8
TRUE -2 Uint32
TRUE -2 Uint32
TRUE 0 Uint8
TRUE 0 Uint8
TRUE 0 Uint8
TRUE 0 Uint8
TRUE - Uint8
TRUE -2 Uint32
TRUE -2 Uint32
TRUE 0 Uint8
TRUE 0 Uint8
TRUE 0 Uint8
TRUE 0 Uint8
TRUE - Uint8
TRUE -2 Uint32
TRUE -2 Uint32
TRUE 0 Uint8
TRUE 0 Uint8
TRUE 0 Uint8
325
5 5
