Parameter Lists
5.2.9 8-** Comm. and Options
Par. Parameter description
No. #
8-0* General Settings
8-01 Control Site
8-02 Control Word Source
8-03 Control Word Timeout Time
8-04 Control Word Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Word Timeout
8-07 Diagnosis Trigger
8-08 Readout Filtering
8-1* Ctrl. Word Settings
8-10 Control Word Profile
8-13 Configurable Status Word STW
8-14 Configurable Control Word CTW
8-17 Configurable Alarm and Warningword
8-19 Product Code
8-3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 FC Port Baud Rate
8-33 Parity / Stop Bits
8-34 Estimated cycle time
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Max Inter-Char Delay
8-4* FC MC protocol set
8-40 Telegram Selection
8-41 Parameters for Signals
8-42 PCD Write Configuration
8-43 PCD Read Configuration
8-45 BTM Transaction Command
8-46 BTM Transaction Status
8-47 BTM Timeout
8-48 BTM Maximum Errors
8-49 BTM Error Log
8-5* Digital/Bus
8-50 Coasting Select
8-51 Quick Stop Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
8-57 Profidrive OFF2 Select
8-58 Profidrive OFF3 Select
8-8* FC Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Messages Rcvd
8-83 Slave Error Count
8-9* Bus Jog
8-90 Bus Jog 1 Speed
M0013101
Programming Guide
Default value 4-set-up
[0] Digital and ctrl.word All set-ups
ExpressionLimit All set-ups
1 s 1 set-up
ExpressionLimit 1 set-up
[1] Resume set-up 1 set-up
[0] Do not reset All set-ups
[0] Disable 2 set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[1] Profile default 2 set-ups
[0] Off All set-ups
ExpressionLimit 1 set-up
[0] FC 1 set-up
1 N/A 1 set-up
ExpressionLimit 1 set-up
[0] Even Parity, 1 Stop Bit 1 set-up
0 ms 2 set-ups
10 ms 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
[1] Standard telegram 1 2 set-ups
0 All set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[0] Off All set-ups
[0] Off All set-ups
60 s 1 set-up
21 N/A 1 set-up
0.255 N/A All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
ExpressionLimit All set-ups
[3] Logic OR All set-ups
ExpressionLimit All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
ExpressionLimit All set-ups
Danfoss A/S © 10/2019 All rights reserved.
FC 302 Change Conver-
only during sion index
operation
TRUE -
TRUE -
TRUE -1
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE 0
TRUE -
TRUE 0
TRUE -
TRUE -
TRUE -3
TRUE -3
TRUE -3
TRUE -5
TRUE -
FALSE -
TRUE 0
TRUE 0
FALSE -
TRUE -
FALSE 0
TRUE 0
TRUE -3
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 67
Type
Uint8
Uint8
Uint32
Uint8
Uint8
5 5
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint32
Uint8
Uint8
Uint8
Uint8
Uint32
Uint16
Uint16
Uint16
Uint8
Uint16
Uint16
Uint16
Uint8
Uint8
Uint16
Uint8
Uint32
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint32
Uint32
Uint32
Uint32
Uint16
