Danfoss VLT AutomationDrive FC 301 Programming Manual page 258

Parameter Descriptions
16-70 Pulse Output #29 [Hz]
Range:
0
*
3 3
16-71 Relay Output [bin]
Range:
0
*
16-72 Counter A
Range:
0
*
-
2147483647 ]
16-73 Counter B
Range:
0
*
-
2147483647 ]
256
Function:
NOTICE
[0 - 40000 ]
This parameter is available for
FC 302 only.
View the actual value of pulses at
terminal 29 in digital output mode.
Function:
[0 - 511 ] View the settings of all relays.
Illustration 3.69 Relay Settings
Function:
[-2147483648 View the present value of counter
A. Counters are useful as
comparator operands, see
parameter 13-10 Comparator
Operand.
Reset or change the value either via
digital inputs (parameter group 5-1*
Digital Inputs) or by using an SLC
action (parameter 13-52 SL Controller
Action).
Function:
[-2147483648 View the present value of counter
B. Counters are useful as
comparator operands
(parameter 13-10 Comparator
Operand).
Reset or change the value either via
digital inputs (parameter group 5-1*
Digital Inputs) or by using an SLC
action (parameter 13-52 SL Controller
1 Action).
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
16-74 Prec. Stop Counter
Range:
0
*
16-75 Analog In X30/11
Range:
0
*
16-76 Analog In X30/12
Range:
0
*
16-77 Analog Out X30/8 [mA]
Range:
0
*
16-78 Analog Out X45/1 [mA]
Range:
0
*
16-79 Analog Out X45/3 [mA]
Range:
0
*
3.16.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-80 Fieldbus CTW 1
Range:
0
*
Function:
[0 - Returns the actual counter value of
2147483647 ] precise counter
(parameter 1-84 Precise Stop Counter
Value).
Function:
[-20 - 20 ] View the actual value at input
®
X30/11 of VLT General Purpose I/O
MCB 101.
Function:
[-20 - 20 ] View the actual value at input
®
X30/12 of VLT General Purpose I/O
MCB 101.
Function:
[0 - 30 ] View the actual value at input
X30/8 in mA.
Function:
[0 - 30 ] Shows the actual output value at
terminal X45/1. The value shown
reflects the selection in
parameter 6-70 Terminal X45/1
Output.
Function:
[0 - 30 ] Shows the actual output value at
terminal X45/3. The value shown
reflects the selection in
parameter 6-80 Terminal X45/3
Output.
Function:
[0 - 65535 ] View the 2 byte control word (CTW)
received from the bus-master.
Interpretation of the CTW depends
on the fieldbus option installed and
the CTW profile selected in
parameter 8-10 Control Word Profile.
