Danfoss VLT AutomationDrive FC 301 Programming Manual page 343

Parameter Lists
17-61 Feedback Signal Monitoring
17-7* Position Scaling
17-70 Position Unit
17-71 Position Unit Scale
17-72 Position Unit Numerator
17-73 Position Unit Denominator
17-74 Position Offset
17-75 Position Recovery at Power-up
17-76 Position Axis Mode
17-77 Position Feedback Mode
17-78 Active Position Counter
17-8* Position Homing
17-80 Homing Function
17-81 Home Sync Function
17-82 Home Position
17-83 Homing Speed
17-84 Homing Torque Limit
17-85 Homing Timout
17-86 Homing Flag Behavior
17-9* Position Config
17-90 Absolute Position Mode
17-91 Relative Position Mode
17-92 Position Control Selection
17-93 Master Offset Selection
17-94 Rotary Absolute Direction
5.2.18 18-** Data Readouts 2
Par. Parameter description
No. #
18-0* Maintenance Log
18-00 Maintenance Log: Item
18-01 Maintenance Log: Action
18-02 Maintenance Log: Time
18-03 Maintenance Log: Date and Time
18-2* Motor Readouts
18-27 Safe Opt. Est. Speed
18-28 Safe Opt. Meas. Speed
18-29 Safe Opt. Speed Error
18-3* Analog Readouts
18-36 Analog Input X48/2 [mA]
18-37 Temp. Input X48/4
18-38 Temp. Input X48/7
18-39 Temp. Input X48/10
18-4* PGIO Data Readouts
18-43 Analog Out X49/7
18-44 Analog Out X49/9
18-45 Analog Out X49/11
18-5* Active Alarms/Warnings
18-55 Active Alarm Numbers
18-56 Active Warning Numbers
18-6* Inputs & Outputs 2
18-60 Digital Input 2
M0013101
Programming Guide
[1] Warning All set-ups
[0] pu All set-ups
0 N/A All set-ups
1024 N/A All set-ups
1 N/A All set-ups
0 N/A All set-ups
[0] Off All set-ups
[0] Linear Axis All set-ups
[0] Relative All set-ups
[0] Counter 0 All set-ups
[0] No Homing All set-ups
[0] 1st time after power All set-ups
0 N/A All set-ups
150 RPM All set-ups
160 % All set-ups
60.0 s All set-ups
[0] Clear at Powerup All set-ups
[0] Standard All set-ups
[0] Target Position All set-ups
[0] No Operation All set-ups
[0] Absolute Enabled All set-ups
[0] Shortest All set-ups
Default value 4-set-up
0 N/A All set-ups
0 N/A All set-ups
0 s All set-ups
ExpressionLimit All set-ups
0 RPM All set-ups
0 RPM All set-ups
0 RPM All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
