Danfoss VLT AutomationDrive FC 301 Programming Manual page 243

Parameter Descriptions
3.14.10 14-9* Fault Settings
14-90 Fault Level
This is an array parameter with 26 elements. Each of the bits can
be configured to any of the following options. Use this
parameter to customize fault levels.
Option: Function:
[0] Off Use [0] Off with caution as it
ignores all warnings and alarms for
the selected source.
[1] Warning
[2] Trip Changing a fault level from default
option [3] Trip Lock to [2] Trip leads
to the automatic reset of the alarm.
For alarms involving overcurrent,
the frequency converter has a
hardware protection that issues a 3-
minute recovery after 2 consecutive
Failure
10 V low
24 V supply low
1.8 V supply low
Voltage limit
Ground fault during ramping
Ground fault 2 during continous
operation
Torque limit
Overcurrent
Short circuit
Heat sink temperature
Heat sink sensor
Control card temperature
Power card temperature
1)
Heat sink temperature
Heat sink sensor 1)
1)
Power card temperature
Motor phase U missing
Motor phase V missing
Motor phase Wmissing
3)
Current Limit
Locked rotor
Table 3.29 Selection of Action when Selected Alarm Appears
MCT 10 Set-up Software has the element numbers listed in the column ID. Use this table together with MCT 10 Set-up Software to get information
about specific fault levels.
D stands for the default setting.
X stands for a possible option.
1) Only high-power frequency converters.
2) In small and medium power frequency converters, alarm 69, Power card temperature is only a warning.
3) Warning 59 is configured in 1490.19. The current limit warning can be disabled by choice. The alarm cannot be configured.
M0013101
Programming Guide
Alarm Element in
parameter 14-90 F
ault Level
1 1490.0
47 1490.1
48 1490.2
64 1490.3
14 1490.4
45 1490.5
12 1490.6
13 1490.7
16 1490.8
29 1490.9
39 1490.10
65 1490.11
69 1490.12
244 1490.13
245 1490.14
247 1490.15
30 1490.16
31 1490.16
32 1490.16
59 1490.19
99 1490.20
Danfoss A/S © 10/2019 All rights reserved.
14-90 Fault Level
This is an array parameter with 26 elements. Each of the bits can
be configured to any of the following options. Use this
parameter to customize fault levels.
Option: Function:
overcurrent incidents. This hardware
protection cannot be overruled.
[3] Trip Lock
[4] Trip w. This option adds a delay between
delayed reset automatic resets, otherwise it is the
same as option [2] Trip. The delay
prevents a situation where reset is
attempted repeatedly for an
overcurrent situation. Hardware
protection of the frequency
converter forces the 3-minute
recovery time after 2 consecutive
overcurrents (within a short time
window).
Off Warning Trip
X D –
X – –
X – –
X D –
– – D
– – D
X D –
– – X
– – X
– – X
– – X
– – X
– 2) X
– – X
– – X
– – X
– – X
– – X
– – X
X D –
– – D
Trip Lock Trip with
delayed
reset
– –
D –
D –
– –
X –
X –
– –
D –
D –
D –
D –
D –
D –
D –
D –
D –
D –
D –
D –
– –
X –
241
3 3
