Danfoss VLT AutomationDrive FC 301 Programming Manual page 294

Parameter Descriptions
33-61 Terminal X59/1 Digital Input
Option:
[10] Break prog.
exe nc
[11] Cont. prog.
3 3
exe no
[12] Cont. prog.
exe nc
[13] Start prog. exe
no
[14] Start prog. exe
nc
[15] Program select
33-62 Terminal X59/2 Digital Input
Option:
[0] No function
*
[1] Home switch
no
[2] Home switch
nc
[3] Neg. end
switch no
[4] Neg. end
switch nc
[5] Posi. end
switch no
[6] Posi. end
switch nc
[7] Error clear no
[8] Error clear nc
[9] Break prog.
exe no
[10] Break prog.
exe nc
[11] Cont. prog.
exe no
[12] Cont. prog.
exe nc
[13] Start prog. exe
no
[14] Start prog. exe
nc
[15] Program select
33-63 Terminal X59/1 Digital Output
Option:
[0] No function
*
[1] Moving no
[2] Moving nc
[3] Error no
[4] Error nc
[5] Brake control
no
292
®
VLT AutomationDrive FC 301/302
Function:
Function:
Function:
Danfoss A/S © 10/2019 All rights reserved.
33-63 Terminal X59/1 Digital Output
Option: Function:
[6] Brake control
nc
33-64 Terminal X59/2 Digital Output
Option: Function:
[0] No function
*
[1] Moving no
[2] Moving nc
[3] Error no
[4] Error nc
[5] Brake control
no
[6] Brake control
nc
33-65 Terminal X59/3 Digital Output
Option: Function:
[0] No function
*
[1] Moving no
[2] Moving nc
[3] Error no
[4] Error nc
[5] Brake control
no
[6] Brake control
nc
33-66 Terminal X59/4 Digital Output
Option: Function:
[0] No function
*
[1] Moving no
[2] Moving nc
[3] Error no
[4] Error nc
[5] Brake control
no
[6] Brake control
nc
33-67 Terminal X59/5 Digital Output
Option: Function:
[0] No function
*
[1] Moving no
[2] Moving nc
[3] Error no
[4] Error nc
[5] Brake control
no
[6] Brake control
nc
