16-80 Fieldbus CTW 1
Range: Function:
For more information, refer to the
relevant fieldbus manual.
16-81 Fieldbus Sync. REF
Range: Function:
0 [-2147483648 Only active for Ethernet-based
*
- fieldbus options. Read out of
2147483647 ] master position for synchronizing
via fieldbus.
16-82 Fieldbus REF 1
Range: Function:
0 [-200 - 200 ] View the two-byte word sent with
*
the control word form the Bus-
Master to set the reference value.
For more information, refer to the
relevant fieldbus manual.
16-83 Fieldbus Pos. REF
Range: Function:
NOTICE
0 Custom- [-2147483648
ReadoutUni - 2147483647
This parameter is only valid
t2 CustomRea-
*
with software version 48.XX.
doutUnit2]
Shows the 32-bit position reference
sent in PCD 2 and PCD 3. In
parameters related to PCD 2 and
PCD 3, select [1683] Fieldbus Pos REF
for the fieldbus which is used by
the frequency converter. The value
is in position units defined in
parameter group 17-7* Position
Scaling.
16-84 Comm. Option STW
Range: Function:
0 [0 - 65535 ] Show the status word of the
*
extended fieldbus communication
option.
For more information, refer to the
relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 [0 - 65535 ] View the 2-byte control word (CTW)
*
received from the fieldbus master.
Interpretation of the control word
depends on the fieldbus option
installed and the control word
profile selected in
parameter 8-10 Control Word Profile.
M0013101
Programming Guide
16-86 FC Port REF 1
Range:
0
*
16-87 Bus Readout Alarm/Warning
Range:
0
*
16-89 Configurable Alarm/Warning Word
Range:
0
*
3.16.7 16-9* Diagnosis Readouts
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, that is as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range:
0
*
16-91 Alarm Word 2
Range:
0
*
16-92 Warning Word
Range:
0
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
[-200 - 200 ] View the 2-byte status word (STW)
sent to the fieldbus master.
Interpretation of the status word
depends on the fieldbus option
installed and the control word
profile selected in
parameter 8-10 Control Word Profile.
Function:
[0 - 65535 ] Alarm and warning numbers in hex
as shown in the alarm log. The high
byte contains the alarm, the low
byte contains the warning. The
alarm number is the 1
occurred after the last reset.
Function:
[0 - 65535 ] This alarm/warning word is
configured in
parameter 8-17 Configurable Alarm
and Warningword to match the
actual requirements.
Function:
[0 - Show the alarm word sent via the
4294967295 ] serial communication port in hex
code.
Function:
[0 - View the alarm word sent via the
4294967295 ] serial communication port in hex
code.
Function:
[0 - Show the warning word sent via
4294967295 ] the serial communication port in
hex code.
