Parameter Descriptions
3.15.7 15-2* Historic Log
View up to 50 logged data items via the array parameters
in this parameter group. Data is logged every time an
event occurs (not to be confused with SLC events). Events
in this context are defined as a change in 1 of the
following areas:
•
Digital inputs.
•
Digital outputs.
•
Warning word.
•
Alarm word.
•
Status word.
•
Control word.
•
Extended status word.
Events are logged with value and time stamp in ms. The
time interval between 2 events depends on how often
events occur (maximum once every scan time). Data
logging is continuous, but if an alarm occurs, the log is
saved and the values can be viewed on the display. This
feature is useful, for example when carrying out service
following a trip. View the historic log contained in this
parameter via the serial communication port or via the
display.
15-20 Historic Log: Event
Array [50]
Range: Function:
0 [0 - 255 ] View the event type of the logged
*
events.
15-21 Historic Log: Value
Array [50]
Range: Function:
0 [0 - View the value of the logged event.
*
2147483647 ] Interpret the event values according
to Table 3.32:
Digital
input
Digital
output (not
monitored
in this SW
release)
Warning
word
Alarm word Decimal value. See
M0013101
Programming Guide
15-21 Historic Log: Value
Array [50]
Range:
15-22 Historic Log: Time
Array [50]
Range:
0 ms
3.15.8 15-3* Alarm Log
Parameters in this group are array parameters where up to
10 fault logs can be viewed. 0 is the most recent logged
data, and 9 is the oldest. Fault codes, values, and time
stamp can be viewed for all logged data.
15-30 Fault Log: Error Code
Range:
0
*
Decimal value. See
parameter 16-60 for
description after
converting to binary
15-31 Fault Log: Value
value.
Array [10]
Decimal value. See
Range:
parameter 16-66 for a
0
*
description after
converting to binary
value.
Decimal value. See
parameter 16-92 for a
description.
parameter 16-90 for a
description.
Danfoss A/S © 10/2019 All rights reserved.
Function:
Status word Decimal value. See
Control
word
Extended
status word
Table 3.32 Logged Events
Function:
[0 - View the time at which the logged
*
2147483647 event occurred. Time is measured in
ms] ms since frequency converter start.
The maximum value corresponds to
approximately 24 days, which
means that the count restarts at 0
after this time period.
Function:
[0 - 65535 ] View the fault code and look up its
meaning in chapter 6 Trouble-
shooting.
Function:
[-32767 - View an extra description of the
32767 ] error. This parameter is mostly used
with alarm 38, internal fault.
parameter 16-03 for a
3
description after
converting to binary
value.
Decimal value. See
parameter 16-00 for a
description.
Decimal value. See
parameter 16-94 for a
description.
