Parameter Descriptions
1-40 Back EMF at 1000 RPM
Range: Function:
shaft is turned externally. Back EMF
is normally specified for nominal
motor speed or for 1000 RPM
measured between 2 lines. If the
value is not available for a motor
speed of 1000 RPM, calculate the
correct value as follows. If back EMF
is for example 320 V at 1800 RPM,
it can be calculated at 1000 RPM:
Example
Back EMF 320 V at 1800 RPM. Back
EMF=(Voltage/
RPM)*1000=(320/1800)*1000=178.
NOTICE
When using PM motors, it is
recommended to use brake
resistors.
1-41 Motor Angle Offset
Range: Function:
NOTICE
0 [-32768 -
*
32767 ]
This parameter is only active
when parameter 1-10 Motor
Construction is set to [1] PM,
non-salient SPM (Permanent
Magnet Motor).
Enter the correct offset angle
between the PM motor and the
index position (single-turn) of the
attached encoder or resolver. The
value range of 0–32768
corresponds to 0–2 x pi (radians).
To obtain the offset angle value:
After frequency converter start-up,
apply DC hold and enter the value
of parameter 16-20 Motor Angle into
this parameter.
1-44 d-axis Inductance Sat. (LdSat)
Range: Function:
Size [0 - 1000 This parameter corresponds to the
related mH] inductance saturation of Ld. Ideally,
*
this parameter has the same value
as parameter 1-37 d-axis Inductance
(Ld). If the motor supplier provides
an induction curve, enter the
induction value at 200% of the
nominal value.
M0013101
Programming Guide
1-45 q-axis Inductance Sat. (LqSat)
Range:
Size
related
*
1-46 Position Detection Gain
Range:
120 %
*
1-47 Torque Calibration
Option:
[0]
[1]
[2]
[3]
