Parameter Descriptions
13-10 Comparator Operand
Option:
[0]
DISABLED
3
3
[1]
Reference %
[2]
Feedback %
[3]
Motor speed
[4]
Motor Current
[5]
Motor torque
[6]
Motor power
[7]
Motor voltage
[8]
DC-link
voltage
[9]
Motor Thermal Value is in percent.
[10]
Drive thermal
[11]
Heat sink
temp.
[12]
Analog input
AI53
[13]
Analog input
AI54
[14]
Analog input
AIFB10
[15]
Analog input
AIS24V
[17]
Analog input
AICCT
[18]
Pulse input
FI29
[19]
Pulse input
FI33
[20]
Alarm number The number of registered alarms.
[21]
Warning
number
[22]
Analog input
x30 11
[23]
Analog input
x30 12
[30]
Counter A
[31]
Counter B
[32]
Process PID
Error
[33]
Process PID
Output
[34]
Analog Input
x48/2
206
®
VLT
AutomationDrive FC 301/302
Function:
Select the variable to be monitored
by the comparator.
The comparator is disabled.
The resulting remote reference in
percent.
[RPM] or [Hz], as set in
parameter 0-02 Motor Speed Unit.
[RPM] or [Hz], as set in
parameter 0-02 Motor Speed Unit.
Value is in percent.
Value is in percent.
Value is in percent.
Value is in percent.
AIFB10 is internal 10 V supply.
AIS24V is a 24 V switch mode
power supply.
Value is in [°]. AICCT is control card
temperature.
Value is in percent.
Value is in percent.
Value of the PID error
(parameter 18-90 Process PID Error).
Value of the PID output
(parameter 18-91 Process PID
Output).
Danfoss A/S © 10/2019 All rights reserved.
13-10 Comparator Operand
Option:
Function:
[35]
Temp Input
x48/4
[36]
Temp Input
x48/7
[37]
Temp Input
x48/10
NOTICE
[38]
Actual Position
This option is only available
for software version 48.XX
[39]
Safe Opt.
Speed Error
[43]
Analog input
X49/1
[44]
Analog input
X49/3
[45]
Analog input
X49/5
[50]
FALSE
Use to enter the fixed value of false
in the comparator.
[51]
TRUE
Use to enter the fixed value of true
in the comparator.
[52]
Control ready
The control board receives supply
voltage.
[53]
Drive ready
The frequency converter is ready for
operation and applies a signal on
the control board.
[54]
Running
The motor runs.
[55]
Reversing
The output is active when the
frequency converter runs counter-
clockwise (the logical product of
the status bits running AND
reverse).
[56]
In range
The motor runs within the
programmed current and speed
ranges set in
parameter 4-50 Warning Current Low
to parameter 4-53 Warning Speed
High.
[60]
On reference
The motor runs on reference.
[61]
Below
The motor runs at a reference
reference, low
which is less than the value in
parameter 4-54 Warning Reference
Low.
[62]
Above ref,
The motor runs at a reference
high
which exceeds the value in
parameter 4-55 Warning Reference
High.
[65]
Torque limit
The torque exceeds the value in
parameter 4-16 Torque Limit Motor
M0013101
