Parameter Description

3.15 Parameters 16-** Data Readouts

16-00 Control Word
Range: Function:
0 [0 - 65535 ] View the Control word sent from the
*
frequency converter via the serial communi-
cation port in hex code.
16-01 Reference [Unit]
Range:
0 ReferenceFeed- [-999999 -
backUnit 999999
*
ReferenceFeed-
backUnit]
16-02 Reference [%]
Range: Function:
0 % [-200 - 200 View the total reference. The total reference
*
%] is the sum of digital, analog, preset, bus,
and freeze references, plus catch-up and
slow-down.
16-03 Status Word
Range: Function:
0 [0 - 65535 ] View the status word sent from the frequency
*
converter via the serial communication port in
hex code.
16-05 Main Actual Value [%]
Range: Function:
0 % [-100 - 100 View the 2-byte word sent with the status
*
%] word to the bus master reporting the Main
Actual Value. Refer to the VLT
Operating Instructions for further details.
16-09 Custom Readout
Range:
0 CustomRea- [-999999.99 -
doutUnit 999999.99
*
CustomRea-
doutUnit]
MG20O702
Programming Guide
Function:
View the present reference
value applied on impulse
or analog basis in the unit
resulting from the configu-
ration selected in
parameter 1-00 Configu-
ration Mode (Hz, Nm, or
RPM).
®
Profibus
Function:
View the user-defined readouts
as defined in
parameter 0-30 Custom Readout
Unit, parameter 0-31 Custom
Readout Min Value and
parameter 0-32 Custom Readout
Max Value.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
3.15.1 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0 kW [0 - Displays motor power in kW. The value shown
*
10000 is calculated based on the actual motor
kW] voltage and motor current. The value is
filtered, and therefore approx. 30 ms may pass
from when an input value changes to when
the data readout values change. The
resolution of readout value on fieldbus is in
10 W steps.
16-11 Power [hp]
Range: Function:
0 hp [0 - View the motor power in hp. The value
*
10000 hp] shown is calculated based on the actual
motor voltage and motor current. The value
is filtered, and therefore approximately 30 ms
may pass from when an input value changes
to when the data readout values change.
16-12 Motor Voltage
Range: Function:
0 V [0 - 6000 V] View the motor voltage, a calculated value
*
used for controlling the motor.
16-13 Frequency
Range: Function:
0 Hz [0 - 6500 Hz] View the motor frequency, without
*
resonance dampening.
16-14 Motor current
Range: Function:
0 A [0 - 10000 View the motor current measured as a mean
*
A] value, I . The value is filtered, and thus
RMS
approximately 30 ms may pass from when an
input value changes to when the data
readout values change.
16-15 Frequency [%]
Range: Function:
0 % [-100 - View a 2-byte word reporting the actual motor
*
100 %] frequency (without resonance dampening) as a
percentage (scale 0000-4000 hex) of
parameter 4-19 Max Output Frequency. Set
9-16 PCD Read Configuration index 1 to send it
with the status word instead of the MAV.
