Parameter Descriptions
13-40 Logic Rule Boolean 1
Option:
[97] RS Flipflop 3
[98] RS Flipflop 4
3 3
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
[102] Relay 1
[103] Relay 2
[104] Relay 3
[105] Relay 4
[106] Relay 5
[107] Relay 6
[108] Relay 7
[109] Relay 8
[110] Relay 9
[222] Homing Ok
[223] On Target
216
®
VLT AutomationDrive FC 301/302
Function:
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
®
X47/VLT Extended Relay Card MCB
113.
®
X47/VLT Extended Relay Card MCB
113.
®
X47/VLT Extended Relay Card MCB
113.
®
X47/VLT Extended Relay Card MCB
113.
®
X34/VLT Relay Card MCB 105.
®
X34/VLT Relay Card MCB 105.
®
X34/VLT Relay Card MCB 105.
NOTICE
This option is available only
with software version 48.20
and newer.
Homing is completed with the
selected homing function
(parameter 17-80 Homing Function).
NOTICE
This option is available only
with software version 48.20
and newer.
Positioning is completed and the
on target signal is sent when the
actual position is within
parameter 3-05 On Reference
Window for the duration of
parameter 3-09 On Target Time and
the actual speed does not exceed
parameter 3-05 On Reference
Window.
Danfoss A/S © 10/2019 All rights reserved.
13-40 Logic Rule Boolean 1
Option: Function:
NOTICE
[224] Position Error
This option is available only
with software version 48.20
and newer.
The position error exceeds the
value in parameter 4-71 Maximum
Position Error for the time set in
parameter 4-72 Position Error
Timeout.
NOTICE
[225] Position Limit
This option is available only
with software version 48.20
and newer.
The position is outside the limits
set in parameter 3-06 Minimum
Position and
parameter 3-07 Maximum Position.
NOTICE
[226] Touch on
Target
This option is available only
with software version 48.20
and newer.
Target position is reached in touch
probe position mode.
NOTICE
[227] Touch
Activated
This option is available only
with software version 48.20
and newer.
Touch probe positioning active. The
frequency converter monitors the
touch probe sensor input.
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the 1
use on the boolean inputs from
parameter 13-40 Logic Rule Boolean
1 and parameter 13-42 Logic Rule
Boolean 2.
Parameter numbers in square
brackets stand for the boolean
inputs of parameters in parameter
group 13-** Smart Logic Control.
[0] DISABLED Ignores:
st
logical operator to
M0013101
