Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1005] Readout
Transmit Error
Counter
3 3
[1006] Readout
Receive Error
Counter
[1007] Readout Bus
Off Counter
[1013] Warning
Parameter
[1230] Warning
Parameter
[1397] Alert Alarm
Word
[1398] Alert Warning
Word
[1399] Alert Status
Word
[1472] Legacy Alarm
Word
[1473] Legacy
Warning Word
[1474] Leg. Ext.
Status Word
[1500] Operating
hours
[1501] Running Hours
[1502] kWh Counter
[1580] Fan Running
Hours
[1600] Control Word
[1601] Reference
[Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual
Value [%]
[1606] Actual Position Actual position in position units
[1607] Target Position Active target position in position
[1608] Position Error
28
®
VLT AutomationDrive FC 301/302
Function:
Present control word.
Total reference (sum of digital/
analog/preset/bus/freeze reference/
catch up and slow down) in
selected unit.
Total reference (sum of digital/
analog/preset/bus/freeze reference./
catch up and slow down) in
percent.
Present status word.
Actual value as a percentage.
selected in parameter 17-70 Position
Unit.
units selected in
parameter 17-70 Position Unit.
Actual position PI error in position
units selected in
parameter 17-70 Position Unit.
Danfoss A/S © 10/2019 All rights reserved.
0-20 Display Line 1.1 Small
Option: Function:
[1609] Custom
Readout
[1610] Power [kW] Actual power consumed by the
motor in kW.
[1611] Power [hp] Actual power consumed by the
motor in hp.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, that is the output
frequency from the frequency
converter in Hz.
[1614] Motor current Phase current of the motor
measured as effective value.
[1615] Frequency [%] Motor frequency, that is the output
frequency from the frequency
converter in percent.
[1616] Torque [Nm] Actual motor torque in Nm.
[1617] Speed [RPM] Speed in RPM (revolutions per
minute), that is the motor shaft
speed in closed loop.
[1618] Motor Thermal Thermal load on the motor,
calculated by the ETR function.
[1619] Thermistor
Sensor
Temperature
[1620] Motor Angle
[1621] Torque [%]
High Res.
[1622] Torque [%] Present motor load as a percentage
of the rated motor torque.
[1623] Motor Shaft
Power [kW]
[1624] Calibrated
Stator
Resistance
[1625] Torque [Nm]
High
[1628] Angle Error
[1630] DC Link DC-link voltage in the frequency
Voltage converter.
[1631] System Temp.
[1632] Brake Present brake power transferred to
Energy /s an external brake resistor.
Stated as an instant value.
[1633] Brake Energy Brake power transferred to an
Average external brake resistor. The mean
power is calculated continuously for
the most recent 120 s.
[1634] Heatsink Present heat sink temperature of
Temp. the frequency converter. The cutout
