Parameter Descriptions
3.13.7 13-9* User-defined Alerts and
Readouts
Parameters in this group allow the configuration of
application-specific messages, warnings, and alarms.
Use the following parameters to configure the frequency
converter to show a message and perform an action when
a specific event occurs:
•
Parameter 13-90 Alert Trigger – the event that
triggers the user-defined action and message.
•
Parameter 13-91 Alert Action – the action that the
frequency converter performs when the event
defined in parameter 13-90 Alert Trigger occurs.
•
Parameter 13-92 Alert Text – the text that the
frequency converter shows in the display when
the event defined in parameter 13-90 Alert Trigger
occurs.
For example, consider the following use case:
If there is an active signal on digital input 32, the
frequency converter shows the message Valve 5 open and
ramps down to a stop.
To achieve this configuration, make the following settings:
•
Parameter 13-90 Alert Trigger = [37] Digital input
DI32.
•
Parameter 13-91 Alert Action = [5] Stop & warning.
•
Parameter 13-92 Alert Text = Valve 5 open.
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-defined action and
message.
Option: Function:
[0] False
*
[1] True
[18] Reversing
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
M0013101
Programming Guide
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-defined action and
message.
Option:
[37]
[38]
[50]
[51]
[60]
[61]
[70]
[71]
[72]
[73]
[74]
13-91 Alert Action
Array [10]
Select the action that the frequency converter performs when
the event defined in parameter 13-90 Alert Trigger occurs.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
13-92 Alert Text
Range:
Size
related
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
Digital input
DI32
Digital input
DI33
Comparator 4
Comparator 5
Logic rule 4
Logic rule 5
SL Time-out 3
SL Time-out 4
SL Time-out 5
SL Time-out 6
SL Time-out 7
Function:
Info
Warning
Freeze output
Freeze output
& warn
Stop
Stop &
warning
Jogging
Jogging &
warning
Max speed
Max speed &
warn
Stop and trip
Stop and trip
w manual
reset
Trip
Trip w manual
reset
Trip Lock
Function:
[0 - 20 ] Array [10]
Enter the text that the frequency
converter shows in the display
when the event defined in
parameter 13-90 Alert Trigger occurs.
