Parameter Descriptions
8-41 Parameters for Signals
Option: Function:
[1645] Motor Phase U
Current
[1646] Motor Phase V
Current
[1647] Motor Phase
W Current
[1648] Speed Ref.
After Ramp
[RPM]
[1650] External
Reference
[1651] Pulse
Reference
[1652] Feedback[Unit]
[1653] Digi Pot
Reference
[1657] Feedback
[RPM]
[1660] Digital Input
[1661] Terminal 53
Switch Setting
[1662] Analog Input
53
[1663] Terminal 54
Switch Setting
[1664] Analog Input
54
[1665] Analog Output
42 [mA]
[1666] Digital Output
[bin]
[1667] Freq. Input
#29 [Hz]
[1668] Freq. Input
#33 [Hz]
[1669] Pulse Output
#27 [Hz]
[1670] Pulse Output
#29 [Hz]
[1671] Relay Output
[bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop
Counter
[1675] Analog In
X30/11
[1676] Analog In
X30/12
[1677] Analog Out
X30/8 [mA]
[1678] Analog Out
X45/1 [mA]
M0013101
Programming Guide
8-41 Parameters for Signals
Option:
[1679]
[1680]
[1681]
[1682]
[1683]
[1684]
[1685]
[1686]
[1687]
[1689]
[1690]
[1691]
[1692]
[1693]
[1694]
[1695]
[1696]
[1697]
[1698]
[1782]
[1783]
[1788]
[1804]
[1820]
[1821]
[1823]
[1827]
[1828]
[1829]
[1836]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Analog Out
X45/3 [mA]
Fieldbus CTW
1
Fieldbus Sync.
REF
Fieldbus REF 1
Fieldbus Pos.
REF
Comm. Option
STW
FC Port CTW 1
FC Port REF 1
Bus Readout
Alarm/Warning
Configurable
Alarm/Warning
Word
Alarm Word
Alarm Word 2
Warning Word
Warning Word
2
Ext. Status
Word
Ext. Status
Word 2
Maintenance
Word
Alarm Word 3
Warning Word
3
Home Position
Homing Speed
Master Home
Position
Mech Brake
Count
Commanded
Position
Master
Position
Virtual Master
Pos.
Safe Opt. Est.
Speed
Safe Opt.
Meas. Speed
Safe Opt.
Speed Error
Analog Input
X48/2 [mA]
3 3
