Danfoss VLT AutomationDrive FC 301 Programming Manual page 210

Parameter Descriptions
13-10 Comparator Operand
Option:
[151] SL digital
output B
[152] SL digital
3 3
output C
[153] SL digital
output D
[154] SL digital
output E
[155] SL digital
output F
[160] Relay 1
[161] Relay 2
[162] Relay 3
[163] Relay 4
[164] Relay 5
[165] Relay 6
[166] Relay 7
[167] Relay 8
[168] Relay 9
[180] Local
referecnce
active
[181] Remote
reference
active
[182] Start
command
[183] Drive stopped
[185] Drive in hand
mode
[186] Drive in auto
mode
[187] Start
command
given
[190] Digital input
x30/2
[191] Digital input
x30/3
[192] Digital input
x30/4
[193] Digital input
x46/1
208
®
VLT AutomationDrive FC 301/302
Function:
Use the result of the SLC output B.
Use the result of the SLC output C.
Use the result of the SLC output D.
Use the result of the SLC output E.
Use the result of the SLC output F.
Relay 1 is active.
Relay 2 is active.
Active when
parameter 3-13 Reference Site is [2]
Local or when
parameter 3-13 Reference Site is [0]
Linked to hand/auto, at the same
time as the LCP is in hand-on
mode.
Active when
parameter 3-13 Reference Site is [1]
Remote or [0] Linked to hand/auto,
while the LCP is in auto-on mode.
Active when there is an active start
command and no stop command.
A stop command (jog, stop, qstop,
coast) is issued – and not from the
SLC itself.
Active when the frequency
converter is in hand-on mode.
Active when the frequency
converter is in auto-on mode.
Danfoss A/S © 10/2019 All rights reserved.
13-10 Comparator Operand
Option: Function:
[194] Digital input
x46/3
[195] Digital input
x46/5
[196] Digital input
x46/7
[197] Digital input
x46/9
[198] Digital input
x46/11
[199] Digital input
x46/13
NOTICE
[222] Homing OK
This option is available only
with software version 48.20
and newer.
Homing is completed with the
selected homing function
(parameter 17-80 Homing Function).
NOTICE
[223] On Target
This option is available only
with software version 48.20
and newer.
Positioning is completed and the
on-target signal is sent when the
actual position is within
parameter 3-05 On Reference
Window for the duration of
parameter 3-09 On Target Time and
the actual speed does not exceed
parameter 3-05 On Reference
Window.
NOTICE
[224] Position Error
This option is available only
with software version 48.20
and newer.
The position error exceeds the
value in parameter 4-71 Maximum
Position Error for the time set in
parameter 4-72 Position Error
Timeout.
NOTICE
[225] Position Limit
This option is available only
with software version 48.20
and newer.
The position is outside the limits
set in parameter 3-06 Minimum
