Parameter Descriptions
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
[1] AND Evaluates the expression [13-40]
AND [13-42].
[2] OR Evaluates the expression [13-40] OR
[13-42].
[3] AND NOT Evaluates the expression [13-40]
AND NOT [13-42].
[4] OR NOT Evaluates the expression [13-40] OR
NOT [13-42].
[5] NOT AND Evaluates the expression NOT
[13-40] AND [13-42].
[6] NOT OR Evaluates the expression NOT
[13-40] OR [13-42].
[7] NOT AND NOT Evaluates the expression NOT
[13-40] AND NOT [13-42].
[8] NOT OR NOT Evaluates the expression NOT
[13-40] OR NOT [13-42].
13-42 Logic Rule Boolean 2
Option: Function:
[0] False
Select the 2
false) input for the selected logic
rule. See parameter 13-01 Start Event
and parameter 13-02 Stop Event for
more information.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
[11] Below speed
low
[12] Above speed
high
[13] Out of feedb.
range
M0013101
Programming Guide
•
Parameter 13-42 Logic Rule
Boolean 2.
•
Parameter 13-43 Logic Rule
Operator 2.
•
Parameter 13-44 Logic Rule
Boolean 3.
nd
boolean (true or
Danfoss A/S © 10/2019 All rights reserved.
13-42 Logic Rule Boolean 2
Option: Function:
[14] Below feedb.
low
[15] Above feedb.
high
[16] Thermal
warning
[17] Mains out of
range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[39] Start
command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available on
the graphical LCP.
[45] Left key [◄] is pressed. Only available on the
graphical LCP.
[46] Right key [►] is pressed. Only available on the
graphical LCP.
▲
[47] Up key
[ ] is pressed. Only available on the
graphical LCP.
