Parameter Descriptions
4-74 Start Fwd/Rev Function
Option: Function:
[0] Stop The frequency converter stops the
*
motor.
[1] Stop & The frequency converter stops the
Warning motor and shows warning 215, Start
Fwd/Rev.
[2] Stop & Trip The frequency converter stops the
motor and trips with alarm 215,
Start Fwd/Rev.
[3] Qstop The frequency converter performs
the quick stop.
[4] Qstop & The frequency converter performs
Warning the quick stop and shows warning
215, Start Fwd/Rev.
[5] Qstop & Trip The frequency converter performs
the quick stop and trips with alarm
215, Start Fwd/Rev.
[6] Coast The frequency converter coasts the
motor.
[7] Coast & The frequency converter coasts the
Warning motor and shows warning 215, Start
Fwd/Rev.
[8] Coast & Trip The frequency converter coasts the
motor and trips with alarm 215,
Start Fwd/Rev.
[9] Zero Speed The frequency converter ramps
Ref down and keeps the motor
magnetized at 0 speed. In the
positioning and the synchronization
modes, the position controller stays
active and retains the actual
position.
[10] Zero Sp. Ref & Same as option [9] Zero Speed Ref
War. and shows warning 215, Start Fwd/
Rev.
4-75 Touch Timout
Range: Function:
6000.0 s [0.1 - 6000.0 Enter the timeout for the touch
*
s] probe positioning. When the touch
probe positioning is active, if the
frequency converter does not
detect the touch probe sensor
within this time, the frequency
converter trips with alarm 216,
Touch Timeout. The value 6000
equals Off.
M0013101
Programming Guide
3.5.7 4-8* Power Limit
Parameters for configuring the power limit function.
4-80 Power Limit Func. Motor Mode
Select whether the power limit function is enabled. Define the
power limit motor mode in parameter 4-82 Power Limit Motor
Mode.
Option:
[0]
*
[1]
[2]
4-81 Power Limit Func. Generator Mode
Select whether the power limit function is enabled in generating
mode. Define the power limit motor mode in
parameter 4-83 Power Limit Generator Mode.
Option:
[0]
*
[1]
[2]
4-82 Power Limit Motor Mode
Range:
100.0 %
4-83 Power Limit Generator Mode
Range:
100.0 %
3.5.8 4-9* Directional Limits
The directional limits functionality allows to specify
different torque and speed limits for different
combinations of torque application direction and rotation
direction. For example, see Illustration 3.34. In the
illustration, quadrants 1–4 show different combinations of
rotation direction and torque application direction, and the
parameters that act in different quadrants.
Danfoss A/S © 10/2019 All rights reserved.
Function:
Disabled
Enabled
When Activation via a digital input or a
Activated fieldbus.
Function:
Disabled
Enabled
When Activation via a digital input or a
Activated fieldbus.
Function:
[0.0 - Enter the maximum output power
*
200.0 %] when the power limit function is
active. Related parameters:
parameter 1-20 Motor Power [kW],
parameter 1-21 Motor Power [HP].
Function:
[0.0 - Enter the maximum generating
*
200.0 %] power when the power limit
function is active. Related
parameters: Parameter 1-20 Motor
Power [kW], parameter 1-21 Motor
Power [HP].
