Parameter Lists

5.2 Parameter Lists and Options

NOTICE
Following is a comprehensive list of parameters. Based on the software version and installed option, the parameters
may vary in your drive.
5.2.1 0-** Operation / Display
Par. Parameter description
No. #
0-0* Basic Settings
0-01 Language
0-02 Motor Speed Unit
0-03 Regional Settings
0-04 Operating State at Power-up (Hand)
0-09 Performance Monitor
0-1* Set-up Operations
0-10 Active Set-up
0-11 Edit Set-up
0-12 This Set-up Linked to
0-13 Readout: Linked Set-ups
0-14 Readout: Edit Set-ups / Channel
0-15 Readout: actual setup
0-2* LCP Display
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-25 My Personal Menu
0-3* LCP Custom Readout
0-30 Unit for User-defined Readout
0-31 Min Value of User-defined Readout
0-32 Max Value of User-defined Readout
0-33 Source for User-defined Readout
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
0-4* LCP Keypad
0-40 [Hand on] Key on LCP
0-41 [Off] Key on LCP
0-42 [Auto on] Key on LCP
0-43 [Reset] Key on LCP
0-44 [Off/Reset] Key on LCP
0-45 [Drive Bypass] Key on LCP
0-5* Copy/Save
0-50 LCP Copy
0-51 Set-up Copy
0-6* Password
0-60 Main Menu Password
0-61 Access to Main Menu w/o Password
0-65 Personal Menu Password
0-66 Access to Personal Menu w/o Password
0-67 Bus Password Access
0-68 Safety Parameters Password
0-69 Password Protection of Safety Parameters
0-7* Clock Settings
0-70 Date and Time
0-71 Date Format
0-72 Time Format
0-73 Time Zone Offset
0-74 DST/Summertime
M0013101
Programming Guide
Default value 4-set-up
[0] English 1 set-up
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[1] Forced stop, ref=old All set-ups
0 % All set-ups
[1] Set-up 1 1 set-up
[1] Set-up 1 All set-ups
[0] Not linked All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
ExpressionLimit All set-ups
1614 All set-ups
1610 All set-ups
1613 All set-ups
1602 All set-ups
ExpressionLimit 1 set-up
[0] None All set-ups
0 CustomReadoutUnit All set-ups
100 CustomReadoutUnit All set-ups
[240] Default Source All set-ups
0 N/A 1 set-up
0 N/A 1 set-up
0 N/A 1 set-up
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[1] Enabled All set-ups
[1] Enabled All set-ups
[0] No copy All set-ups
[0] No copy All set-ups
100 N/A 1 set-up
[0] Full access 1 set-up
200 N/A 1 set-up
[0] Full access 1 set-up
0 N/A All set-ups
300 N/A 1 set-up
[0] Disabled 1 set-up
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
0 min 2 set-ups
[0] Off 1 set-up
