Parameter Descriptions
40-28 Back EMF Protection
Option:
[1] Enabled
*
40-29 B-EMF Protection Log Readout
3 3
Range:
0
*
40-40 Fault Log: Ext. Reference
Range:
0 %
*
200 %]
40-41 Fault Log: Frequency
Range:
0 Hz
*
40-42 Fault Log: Current
Range:
0 A
*
40-43 Fault Log: Voltage
Range:
0 V
*
40-44 Fault Log: DC Link Voltage
Range:
0 V
*
40-45 Fault Log: Control Word
Range:
0
*
306
Function:
Function:
[0 - 65535 ] Readout parameter to log events if
the Back EMF has been enabled or
disabled. The range of the read-out
parameter is between [0x0 -0xFFFF]
hex. The value indicates the bit
pattern to identify the current state
of Back EMF in the drive.
Bit 1 is set: When Back EMF is
enabled the bit is set to 1. Once
enabled the Back EMF cannot be
reversed.
Bit 1 and Bit 2: Motor frequency
exceeded Back EMF limitation. Bit 2
can be reversed.
Bit 1, Bit 2, and Bit 3: The drive has
been coasted as motor frequency
exceeded the Back EMF limitation.
Bit 1, Bit 2, Bit 3, Bit 4: The drive
has generated an over-voltage
alarm because the drive has
coasted as the motor frequency
exceeded Back EMF limitation.
Function:
[-200 -
Function:
[0 - 6500 Hz]
Function:
[0 - 10000 A]
Function:
[0 - 6000 V]
Function:
[0 - 10000 V]
Function:
[0 - 65535 ]
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
40-46 Fault Log: Status Word
Range:
0
*
3.29.1 40-5* Advanced Control Settings
Parameters for configuring the advanced motor control
settings.
40-50 Flux Sensorless Model Shift
Use this parameter to enable or disable the shifting between flux
model 1 and flux model 2 at low speed. See also
parameter 1-66 Min. Current at Low Speed.
Option:
[0]
[1]
40-51 Flux Sensorless Corr. Gain
Range:
Size
related
*

3.30 Parameters: 42-** Safety Functions

The parameters in this parameter group are available when
a safety option is installed in the frequency converter. For
information about the safety-related parameters, see the
operating instructions for the safety options:
•
•
42-00 Speed Deviation Timer
Range:
10 ms
*
42-01 Fast Ramp
Option:
[0]
*
[1]
42-10 Measured Speed Source
Option:
[0]
[1]
Function:
[0 - 65535 ]
Function:
Off
On
Function:
[0.1 - 200.0 ]
®
VLT Safety Option MCB 150/151 Operating
Instructions.
®
VLT Safety Option MCB 152 Operating Instructions.
Function:
[10 - 5000 Enter the time for which a speed
ms] deviation above 120 RPM between
estimated and measured speed is
allowed.
Function:
No
Yes Select this option if fast ramping is
needed with poor resolution of
measured speed.
Function:
None
Safe Option Source of the speed feedback.
M0013101
