Danfoss VLT AutomationDrive FC 301 Programming Manual page 217

Parameter Descriptions
13-40 Logic Rule Boolean 1
Option: Function:
[20] Alarm (trip)
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[39] Start
command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available on
the graphical LCP.
[45] Left key
[◄] is pressed. Only available on the
graphical LCP.
[46] Right key [►] is pressed. Only available on the
graphical LCP.
▲
[47] Up key
[
graphical LCP.
▼
[48] Down key
[
graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
M0013101
Programming Guide
] is pressed. Only available on the
] is pressed. Only available on the
Danfoss A/S © 10/2019 All rights reserved.
13-40 Logic Rule Boolean 1
Option: Function:
[74] SL Time-out 7
[75] Start
command
given
[76] Digital input
x30/2
[77] Digital input
x30/3
[78] Digital input
x30/4
[79] Digital input
x46/1
[80] Digital input
x46/3
[81] Digital input
x46/5
[82] Digital input
x46/7
[83] Digital input
x46/9
[84] Digital input
x46/11
[85] Digital input
x46/13
[90] ATEX ETR cur. Available if parameter 1-90 Motor
warning Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 164, ATEX ETR cur.lim.alarm is
active, the output is 1.
[91] ATEX ETR cur. Available if parameter 1-90 Motor
alarm Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 166, ATEX ETR freq.lim.alarm is
active, the output is 1.
[92] ATEX ETR freq. Available if parameter 1-90 Motor
warning Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 163, ATEX ETR cur.lim.warning
is active, the output is 1.
[93] ATEX ETR freq. Available if parameter 1-90 Motor
alarm Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
warning 165, ATEX ETR
freq.lim.warning is active, the output
is 1.
[94] RS Flipflop 0 See parameter group 13-1*
Comparators.
[95] RS Flipflop 1 See parameter group 13-1*
Comparators.
[96] RS Flipflop 2 See parameter group 13-1*
Comparators.
3 3
215
