Parameter Descriptions
7-90 Position PI Feedback Source
Option:
[2] MCB 102
3 3
[3] MCB 103
[4] MCO
Encoder 1
X56
[5] MCO
Encoder 2
X55
[11] MCB 15X
[12] MCB 102
Absolute
[13] 24V
encoder
27/29
[20] None
7-91 Position PI Droop
Range:
0.0 °
*
7-92 Position PI Proportional Gain
Range:
0.0150
*
1.000 ]
182
Function:
®
This is only available for VLT
MCB 102. Configure the encoder interface in
parameter groups 17-0*, 17-1*, and 17-2*.
®
This is only available for VLT
MCB 103. Configure the resolver interface in
parameter group 17-5* Resolver Interface.
The MCO encoder 1 X56 is only available with
motion control options MCO 305, MCO 350,
and MCO 351.
Configure the encoder interface in parameter
group 32-3* Encoder 1.
The MCO encoder 1 X56 is only available with
motion control options MCO 305, MCO 350,
and MCO 351.
Configure the encoder interface in parameter
group 32-0* Encoder 2.
The option is only available for VLT
Option MCB 102 with version 4.00 and newer
and when parameter 17-00 Encoders Connected
is set to [1] Two Encoders.
Single signal generated from 24 V High
Threshold Logic (HTL) encoder connected to
terminals 27 and 29. Configure the 24 V
encoder interface in parameter group 5.7* 24V
Encoder Input.
Program terminals 27/29 to [0] No operation.
No position feedback is received. This means
that actual position remains unchanged. For
example, when the drive is used for operating
nd
a 2 motor without change in position via
setup change.
Function:
[0.0 - 360.0 °] Enter the motor angle deviation at
100% load in a load sharing system.
The system is 2 or more mechan-
ically connected motors in
positioning or synchronization
mode. In positioning mode,
configure parameter 7-01 Speed PID
Droop to allow a speed deviation.
Function:
NOTICE
[0.000 -
This parameter is only
available with software version
48.XX.
Enter the proportional gain for the
position PI controller. Increasing the
Danfoss A/S © 10/2019 All rights reserved.
®
VLT AutomationDrive FC 301/302
7-92 Position PI Proportional Gain
Range:
Encoder Option
7-93 Position PI Integral Time
Resolver Option
Range:
20000.0
ms
*
7-94 Position PI Feedback Scale Numerator
Range:
®
Encoder
1
*
7-95 Position PI Feebback Scale Denominator
Range:
1
*
7-97 Position PI Max Speed Above Master
Range:
100 RPM
Function:
gain value makes the control more
dynamic but less stable. 0=Off.
Function:
NOTICE
[1.0 -
20000.0 ms]
This parameter is only
available with software version
48.XX.
Enter the integral time for the
position PI controller. Decreasing
the value makes the control more
dynamic but less stable. 20000=Off.
Function:
NOTICE
[-2000000000
-
This parameter is only
2000000000 ]
available with software version
48.XX.
This parameter is the numerator in
the equation which defines the
gear ratio between the motor and
the feedback device when the
feedback device is not mounted on
the motor shaft.
Encoder revolutions =
× Motor revolutions
Function:
NOTICE
[-2000000000
-
This parameter is only
2000000000 ]
available with software version
48.XX.
See parameter 7-94 Position PI
Feedback Scale Numerator.
Function:
NOTICE
[0 - 1500
*
RPM]
This parameter is only
available with software version
48.XX.
Enter the value by which the
follower speed is allowed to exceed
Par . 7 − 94
Par . 7 − 95
